Synthes Hybrid Fixator Proximal Tibia Frame Technique Manual page 9

Optional Frame Configurations
Frame with anterior, medial and lateral
carbon fiber rods.
Additional reading
Stamer, D., R. Schenk, B. Staggers, K. Aurori, B. Aurori, and F.F. Behrens.
"Bicondylar Tibial Plateau Fractures Treated with a Hybrid Ring External Fixator:
a Preliminary Study." Journal of Orthopaedic Trauma. 1994;8,6. 455–461.
Weiner, L., M. Kelley, E. Yang, J. Steuer, N. Watnick, M. Evans, and M. Bergman.
"The Use of Combination Internal Fixation and Hybrid External Fixation in Severe
Proximal Tibia Fractures." Journal of Orthopaedic Trauma. 1995;9,3. 244–250.
Large multi-pin clamp frame with anterior
and medial carbon fiber rods.
Synthes
