Synthes Hybrid Fixator Proximal Tibia Frame Technique Manual page 8

Using the Adjustable Wire / Pin Clamp (393.464)
1
Hold clamp in hand as with a
syringe.
2
Pull vise plates apart with thumb
and fingers.
3
Hook top vise plate over ring and
release.
Synthes Hybrid Fixator— Proximal Tibia Frame Technique Guide
15 mm
Clamp-locking
nut
The wire/pin connection provides up to 15 mm
of excursion for versatile wire or pin placement.
Wire-locking
nut
