Synthes Hybrid Fixator Proximal Tibia Frame Technique Manual page 4

Recommended Components for Hybrid Fixator
Product Item
Number
294.785*
5.0 mm Self-Drilling
Schanz Screw, 175 mm
292.38 –
Spade-Point Reduction Wire
292.41
(or Spade-Point Wire)
390.005*
Large Combination Clamp
393.436
Ring-to-Rod Clamp
393.464
Adjustable Wire / Pin Clamp
Notes: Additional components are required for optional
frame configurations.
Additionally available lengths of stainless steel self-drilling
Schanz screws, stainless steel non – self-drilling Schanz screws
and titanium self-drilling Schanz screws may also be used.
* Although some components are MR Conditional, the
standard hybrid frame is not safe to be utilized in an
MR environment.
Synthes Hybrid Fixator— Proximal Tibia Frame Technique Guide
Quantity
Needed
3
2
3
2
5
