Introduction

Connect Tech's Spacely Carrier for NVIDIA
applications, or any application where situational awareness is critical. Spacely enables users to simultaneously
connect up to 6 MIPI CSI-2 cameras as well as offering built-in expansion for a GPS/GNSS module.
This carrier includes a multi-I/O port specifically designed to allow easy connection to OEM Autopilots such as the
Pixhawk. Other onboard interconnects include 2x GbE, 1x HDMI, USB 3.0, USB 2.0, USB CLIENT, as well as
miniPCIe and mSATA expansion.

Product Features and Specifications

Module Compatibility
PCB Size / Overall Size
Display
Camera Inputs
Ethernet
USB
SATA
Audio
Serial
Mini-PCIe
SD Card
CAN Bus
Optional Sensor
Misc.
Power Requirements
Operating Temperature
Weight
Accessories
Warranty and Support
Document: CTIM-00153
Revision: 0.14
Spacely Carrier for NVIDIA® Jetson™ TX2/TX2i/TX1
Jetson™ TX2/TX2i/TX1 is an ideal product for unmanned vehicle
®
Specifications
Jetson™ TX2, Jetson™ TX2i and Jetson™ TX1
®
NVIDIA
125mm x 95mm (4.92" x 3.74")
1x HDMI
6 x2 Lane MIPI CSI-2or
3 x4 Lane MIPI CSI-2
2x Gigabit Ethernet (10/100/1000)
2x Micro USB 3.0 (Integrated USB 2.0)
2x USB 2.0
1x USB CLIENT
1x USB 2.0 to Mini-PCIe Slot
1x mSATA Full Size
HDMI Integrated
2x 3.3V from Jetson UART0 and UART1
1x Mini-PCIe (PCIe & USB 2.0)
1x microSD Card Slot
1x CAN 2.b Port
1x GPS/GNSS Module (optional)
1x I2C Link (+3.3V I/O)
1x SPI Channel (+3.3V I/O)
16x GPIO (3.3V level shifted)
System Control
+12V to +22V DC Input
o o
-40 C to +85 C
90.7grams (0.2lbs)
Cable Kit
1 Year Warranty and Free Support
