Dip Switch And Button Summary & Locations; On-Board Indicator Led's - Connect Tech NVIDIA Jetson TX2 User Manual

Designator
P2
P3
P4A/B
P5
P6
P7
P8
P9
P10
P11
P12
P13
P14
P15
P16A/B/C
P17A/B/C
P20
P22
DIP Switch and Button Summary & Locations
Designator
SW1
SW2
SW3
S1-A
S1-B
S3-A
S3-B
S3-C
S3-D

On-Board Indicator LED's

Document: CTIM-00153
Revision: 0.14
HDMI Right Angle Type D (Micro) Connector
Mini-PCIe SIM Card Slot
Ethernet Connector (10/100/1000)
NVIDIA Jetson Module Connector
MicroSD Card Slot
1x CAN Port Connector
2x USB 2.0 Ports
mSATA Full Sized Slot
+12V to +22V DC Power Input
USB 2.0 Link 0 OTG Micro-AB Connector
System I/O including UART and I2C signals
GPIO Connector
Micro USB 3.0 Link 1
Micro USB 3.0 Link 0
2 Lane CSI Connector (PEX Micro Coax)
2/4 Lane CSI Connector (PEX Micro Coax)
Mini-PCIe Full Sized Slot
Fan Connector
Push button to turn on system
Push button to reset system
Push button to place Jetson into force recovery
When ON, removes the need to push the power button to turn on the system
Used for Factory Test (Leave OFF)
Selects 2 or 4 Lane CSI to P17A
Selects 2 or 4 Lane CSI to P17B
Selects 2 or 4 Lane CSI to P17C
TX2/TX2i/TX1 Compatibility mode
LED
D32
Page 11 of 29
Connect Tech Inc. 800-426-8979 | 519-836-1291
Spacely Carrier for NVIDIA® Jetson™ TX2/TX2i/TX1
Description
Description
Description
All Power OK
Users Guide
www.connecttech.com
Date: 2018-11-13
