Installation and Basic Configuration Guide

1 Preparation Before Installation

1.1 Product Overview

1.1.1 Product Types

According to antenna connection, devices can be divided into following types:
Number Physical Features
1
Single 3G/4G module, one external GPS antenna
2 Single 3G/4G module, six external antennas
3 Dual 3G/4G modules, three external antennas
4 Dual 3G/4G modules, seven external antennas
1.1.2 RG-MTFi-M520
Front Panel
Figure 1-1 Front Panel
Rear Panel
Figure 1-2 Single 3G/4G Module and One External GPS Antenna
Figure 1-3 Single 3G/4G Module and Six External Antenna
Preparation Before Installation
