Operating Unisab III control
Shutdown/alarm
Low process in temperature
Emergency stop
Low process out temperature
High process out temperature
Low-low oil pressure
1) May occur as alarm in MAN and AUTO.
2) Shutdown at prelubrication. Alarm during operation.
3) HPO/HPC only.
4) The shutdown Low oil pump pressure during operation applies to SAB 80. The shutdown is only activated at
a discharge pressure level below 16 bar.
5) Shutdown relay can be deactivated.
NA = Not available
Table 17: Shutdowns and alarms with identification numbers for reciprocating compressors
For the optional protocols RS2LAN, Profibus DP and Modbus TCP you can also find the ID
numbers in the dedicated manuals.
Operating manual - Unisab III
005650-en 2013.10
alarm + shutdown
shutdown
alarm + shutdown
alarm + shutdown
shutdown
41/48
Id
Danbuss Profibus/
Modbus
NA 96
NA 97
NA 98
NA 99
NA 104
