Menu level 1 Menu level 2
Service Maintenance
Diagnosis
Remote monitor
Trend
Event
Table 5: Unisab III HMI menu tree
Menu level 3
Service timers
Maint. compr.
Drive (VSD/Modbus only)
Hardware Analog inputs
Analog outputs
Digital inputs
Digital outputs
Software Software version
Power on
Zero cap. pos. (screws only)
COP
Proficom
Rotatune piston (rota rec. only)
Sep. velocity (Screws only)
Misc. functions
Superuser password
Examine all parameters
14/48
Operating Unisab III control
Menu level 4
