Menu level 1 Menu level 2
Control values Motor
Capacity
Table 3: Unisab III HMI menu tree
Menu level 3
Values
Current Control
Power Control
Speed Control (VSD only)
Speed ref. (VSD/Modbus only)
Frequency (VSD/Modbus only) /DA
Final speed (VSD/Modbus only) /LS
Voltage (VSD/Modbus only)
Torque Nm (VSD/Modbus only)
Torque % (VSD/Modbus only) /DA
Mains voltage (VSD/Modbus only) /LS
DC bus voltage (VSD/Modbus only)
U phase temp. (VSD/Modbus only) /LS
V phase temp. (VSD/Modbus only) /LS
W phase temp. (VSD/Modbus only /LS)
Heatsink temp. (VSD/Modbus only /DA)
Rectifier temp. (VSD/Modbus only /LS)
Ambient temp. board (VSD/Modbus only)
Values
Capacity Control
Cap. slide pos. (Not recip.)
Vi ratio (SAB157HR, SABflex, SABcube)
Vi slide pos. Control (Auto Vi only)
Yield
12/48
Operating Unisab III control
Menu level 4
