tion is required, the automation system must be
combined with other devices;
the product may not be used until the automation
system "commissioning" procedure has been per-
formed as specified in the "Automation system te-
sting and commissioning" section;
the system power supply line must include a circuit
breaker device with a contact gap allowing com-
plete disconnection in the conditions specified by
class III overvoltage;
use unions with IP55 or higher protection when
connecting hoses, pipes or cable glands;
the electrical system upstream of the automation
system must comply with the relevant regulations
and be constructed to good workmanship stan-
dards;
this appliance can be used by children aged from
8 years and above and persons with reduced
physical, sensory or mental capabilities or lack of
experience and knowledge if they have been gi-
ven supervision or instruction concerning use of
the appliance in a safe way and understand the
hazards involved;
before starting the automation system, ensure that
there is no-one in the immediate vicinity;
before proceeding with any cleaning or mainte-
nance work on the automation system, disconnect
it from the electrical mains;

2 - INTRODUCING THE PRODUCT

2.1 - Technical characteristics
DATI TECNICI
Torque
Temporary service
Opening time 90°
Control unit
Max. number of transmitters storage
FIX CODE
Max. number of transmitters storage
ROLLING CODE
Power supply
230 Vac power supply line fuses
Standby power
Rated power
Maximum input power
Red and green light integrated
Red and green light bar
Sound pressure
Protection class
32
special care must be taken to avoid crushing
between the part operated by the automation sy-
stem and any fixed parts around it;
children must be supervised to ensure that they do
not play with the equipment.
Frequently examine the installation for imba-
lance where applicable and signs of wear or
damage to cables, springs and mounting.
Do not use if repair or adjustment is necessary.
Since the automation system exceeds 10 kg in
weight, it must be handled using a truck (IEC
60335-2-103:2015)
The automation system component packaging
material must be disposed of in full observan-
ce of current local waste disposal legislation.
KEY AUTOMATION reserves the right to amend
these instructions if necessary; they and/or
any more recent versions are available at
keyautomation.it
900ALT324KF 900ALT324LFK 900ALT424K
40 Nm
50 %
1 sec
CT10224F
230 V ±10% 120 V ±10%
50-60Hz 50-60Hz
10 W
(1)
30 W
60 W
yes
no
< 70 dB(A)
IP 54
ATTENTION !
ATTENTION !
ATTENTION !
900ALT424LK
200 Nm
80 %
3,5 sec
CT10224
150 transmitters
150 transmitters
230 V ±10% 120 V ±10%
50-60Hz 50-60Hz
1.6 A slow-acting
10 W
(1)
40 W
90 W
yes
yes
< 70 dB(A)
IP 54
www.
900ALT624K 900ALT624LK
305 Nm
80 %
6 sec / 12 sec*
CT10224
230 V ±10% 120 V ±10%
50-60Hz 50-60Hz
10 W
(1)
40 W
100 W
yes
yes
< 70 dB(A)
IP 54
