Key Automation ALT6K Series Instructions And Warnings For Installation And Use
Automation for rod barriers up to 6 m
Hide thumbs
Also See for ALT6K Series:
Subscribe to Our Youtube Channel
Related Manuals for Key Automation ALT6K Series
Summary of Contents for Key Automation ALT6K Series
- Page 1 Instructions and warnings for installation and use ALT6K Automation for rod barriers up to 6 m Management System ISO 9001:2008 www.tuv.com ID 9105043769...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Safety warnings pag. 3 Product Introduction pag. 4 Technical characteristics pag. 4 Preliminary Checks pag. 4 Installing the Product pag. 5 Installing pag. 5 Release pag. 5 Adjustment of rod angle pag. 5 Inversion of direction of opening pag. - Page 3 1 - SAFETY WARNINGS should this occur, disconnect the power supply immediately and WARNING contact a Key Automation Service Centre. Use of the automation system in these conditions may cause hazards; ORIGINAL INSTRUCTIONS - important safety instructions. Fol- low the instructions since incorrect installation can lead to se- never place automation system components near to sources of heat vere inquiry! Save these instructions.
-
Page 4: Technical Characteristics
2 - INTRODUCING THE PRODUCT 2.1 - Technical characteristics TECHNICAL SPECIFICATIONS 900ALT624K Torque 250 Nm Temporary service 80 % Opening time 6/*12 sec Control unit CT10224 Power supply Vac (Vdc) 230 (24) Motor absorption 1,3 A Input power 300 W Integrated lights Protection class IP 54... -
Page 5: Adjustment Of Rod Angle
4 - PRODUCT INSTALLATION 4.1 - Installation Before proceeding with the installation, check the integrity of the NOTE: verify that the plate is perfectly leveled and parallel to the opening barrier. product and that all components are present in the package. 1. -
Page 6: Testing
5- TESTING AND COMMISSIONING THE AUTOMATION The testing of the system must be performed by qualified techni- regulations, in particular the EN12445 standard, which specifies the cians who must perform the tests required by relevant legislation testing methods for the automation of doors and gates. related to risks, ensuring compliance with the provisions of the 5.1 Testing Check the correct operation of all connected devices (photocells,... -
Page 7: Instructions And Warnings For
Agree with your riers. However, Key Automation is not the manufacturer of your au- installer on a maintenance plan on a periodic basis; Key Automation... - Page 8 IMAGES Fig. 1 - Space dimensions/Main components 900ALT624K 1188 VERTICAL DIAGONAL POSITION POSITION MAIN COMPONENTS SPRING + SHORT TIE ROD VERTICAL POSITION SPRING + LONG TIE ROD DIAGONAL POSITION MOTOR 24 Vdc MECHANICAL STOP ADJUSTING UNLOCK KEY CONTROL BOARD...
- Page 9 Fig. 2 - Typical Installation Fig. 3 - Preparation of the base Fig. 4 - Fixing the barrier body...
- Page 10 Fig. 5 - Fixing round bar/square bar ALUMINUM TUBOLAR BAR Fig. 6 - Adjustment of bar angle Fig. 7 - Inversion of direction of opening and balancing...
- Page 11 Fig. 8 - Release system WARNING: WHEN UNLOCKING THE BAR, THE BAR CAN FALL OR RAISE. DO NOT STAND BELOW THE BAR.
- Page 12 BAR BALACING ALT6K LEGENDA example of spring HOLE NUMBER SPRING POSITION SPRING TYPE type and position: V=vertical position 1=spring + short D=diagonal position tie rod 2=spring + long tie rod 3=HOLE NUMBER D=SPRING POSITION 1=SPRING TYPE BAR + RUBBER BAR + RUBBER BAR + RUBBER BAR + RUBBER + MOBILE STAND...
- Page 13 BAR BALACING ALT6K BAR + RUBBER BAR + FENCE (1x) BAR + FENCE (2x) BAR + FENCE (3x) + FENCE (3x) + MOBILE STAND + MOBILE STAND + MOBILE STAND L= BAR LENGHT L= BAR LENGHT L= BAR LENGHT L= BAR LENGHT L= BAR L= BAR L= BAR...
- Page 14 NOTES...
- Page 15 DECLARATION OF CONFORMITY Il sottoscritto Nicola Michelin, Amministratore Delegato dell’azienda The undersigned Nicola Michelin, General Manager of the company Key Automation srl, Via Alessandro Volta, 30 - 30020 Noventa di Piave (VE) – ITALIA dichiara che il prodotto tipo: declares that the product type: Barriera elettromeccanica irreversibile con asta da 4m o 6m Electromechanical irreversible barrier with 4m or 6m rod ...
- Page 16 Key Automation S.r.l. Via A. Volta 30 - 30020 Noventa di Piave (VE) Instruction version T. +39 0421.307.456 - F. +39 0421.656.98 info@keyautomation.it - www.keyautomation.it 580ISALT REV.02...
