6.4 - Electrical connections

ATTENTION !

MOTOR CONNECTOR

Power supply connection terminal board
M + Power supply motor
M - Power supply motor
V + Power supply encoder
ENC Encoder signal
NEG Maximum encoder power supply
N
L
40
Before making the connections, ensure that the control unit is not powered up
M +
M -
V +
ENC
NEG
BATTERY
POWER SUPPLY
POWER
SUPPLY
1 2
GND 12/24
_
AC/DC
TX
PH2

POWER SUPPLY CONNECTOR

L Power supply live 230 Vac (120 Vac) 50-60 Hz
N Power supply neutral 230 Vac (120 Vac) 50-60 Hz
Earth

DIP SWITCH

Set on "ON" to disable inputs STOP, PH1, PH2
Eliminates the need to bridge the terminal board inputs.
ATTENTION !
with the dip switch ON,
the safety devices are disabled
UP
1 2 3 4
COM OUT
GND 12/24
_
AC/DC
NC
1 2
RX
GND 12/24
_
AC/DC
TX
PH1
ANT
SHIELD
KEY
MENU
DOWN
(RADIO)
SBS
1 2 3 4
GND 12/24 COM OUT
_
AC/DC
NC
RX
ON
1 2 3
