Crosswater Classic Console Series Installation Instructions

Classic Console US-B15/US-T49
Classic Pedestal Basin US-B15/US-P6
Installation Instructions
Introduction
All parts have been fully inspected throughout the production
process and only leaves our factory after a 15-step QC process.
Carefully remove the items from the box and check that all parts have
been supplied.
Installation should be completed by at least two suitably competent
installers
Before beginning installation, please check for any damage that may
have occurred during transport. Note: Damage claims cannot be
made during or after installation.
Improper installation shall result in loss of warranty in case of
damage caused by impacts or rubbing against rough surfaces.
Wall fixings are not supplied. Source fixings which are suitable to the
site wall.
IMPORTANT: Please read these instructions carefully before
beginning and retain for future reference.
We do not accept responsibility for any problems that may occur
through incorrect installation.
Installation notes
The installation must comply with all plumbing codes including local
codes and be installed by a licensed plumbing contractor.
Assemble the parts on a mat to protect against scratching the surface.
Avoid getting cement, grit, sand or masonry products on to the surface.
Protect and cover the basin during the installation period to prevent
damage from occurring.
IMPORTANT: Turn off the main water supply before connecting to
any existing pipework or doing any maintenance.
WARNING! Please check for any hidden pipes and cables, electric
or otherwise, before drilling holes in a wall or floor.

Tools required

Tape Safety
measure glasses
1 / " Hammer
4
drill
Parts supplied - basin stand
x1
x2
Flat head
screwdriver
x6
x7
x2
Floor nipples
x2
Floor nipple washers
x6
Rubber washers
x4
x2
Pencil Spirit
level
