Accessories

• Soft and hard brushes, abrasive pads.
• Pad Holder.
• Standard battery (BAAC00192 code).
• Uprated battery (BAAC00193 code).
• Battery charger (BACA00263 code).

Lifting and transporting the palletized machine

The machine comes packed in a cardboard box by the manufacturer.
Handle with care to avoid impact and ensure the machine is not overturned.

Delivery checks

On taking delivery of the machine, check carefully that the packing and machine it contains are
both intact.

Unpacking

When unpacking the machine, proceed as follows:
• Cut and remove the plastic straps using scissors or nippers;
• Open the box:
• Remove the following items from the packaging:
• operating and maintenance manual, declaration of conformity, certificate of warranty;
• battery charger manual;
• bumper wheel;
• front squeegee:
• brush;
• battery charger.
• Lift the machine out of the box by the handle (fig. 2, ref. 1) and set it down on the floor.
• Pull the handle up at right angles to the machine, referring to the section "Adjusting the handle
rake angle"
• Remove the dirty water tank and the detergent tank and set them on the floor, referring to the
section "Emptying the water/detergent tank" and "Emptying the dirty water tank".
• Tilt the machine backwards and rest the handle on the floor.
• Cut the ties applied to the rear squeegee.
• Install the front squeegee (fig. 2A, ref. 1).
• Install the bumper wheel (fig. 2B, ref. 1).
Keep the packaging materials and store in a safe place: in the event of relocation or shipment
to authorized workshops, the original packaging will ensure that the machine and battery
Fig.2

HANDLING AND INSTALLATION

! WARNING
pack remain undamaged.
1
Fig.2A
1
EN
Fig.2B
12
1
