Command access PD10-UL-M Kit Insert Instructions page 4

Installation Instructions
1.
Remove HEAD COVER
Note: For AHT4/5 & PD11's purchased after 2015 only.
3.
SLIDE PUSH PAD OFF DEVICE
5.
REMOVE BOTH SCREWS ATTACHING HEAD ASSEMBLY TO HOUSING
U S C U S T O M E R S U P P O R T 1 - 8 8 8 - 6 2 2 - 2 3 7 7 | W W W . C O M M A N D A C C E S S . C O M | C A C U S T O M E R S U P P O R T 1 - 8 5 5 - 8 2 3 - 3 0 0 2
2.
REMOVE FRONT AND BACK END CAPS
4.
REMOVE BASERAIL ASSEMBLY FIRST BY REMOVING
4 SCREWS
2
4
6.
REMOVE DOGGING ASSEMBLY AND BACK ACTIVATING
BRACKET SCREWS.
1
2
