chARgiNg PROgRAM

XS 0.8 is equipped with a multi purpose charging program. XS 0.8 charges all batteries 1.2–32Ah and
maintains all batteries 1.2–100Ah in the temperature range of -20˚ to +50˚C (-4˚F to +122˚F).
DESULPHATION BULK
1
1
14.4V Increasing voltage
to 14.4V
0.8A
Max 8h Max 20h

LiMitEd WARRANty

CTEK SWEDEN AB, issues this limited warranty to the original purchaser of
this product. This limited warranty is not transferable. The warranty applies
to manufacturing faults and material defects for 5 years from the date of
purchase. The customer must return the product together with the receipt of
purchase to the point of purchase. This warranty is void if the battery charger
has been opened, handled carelessly or repaired by anyone other than
20016125A XS 0.8, Manual LOW7, Print file 002.indd 5
ABSORPTION ANALYSE
2 3
14.4V Checks if voltage
Declining current drops to 12V
Max 10h
CTEK SWEDEN AB or its authorised representatives. CTEK SWEDEN AB
makes no warranty other than this limited warranty and is not liable for any
other costs other than those mentioned above, i.e. no consequential dam-
ages. Moreover, CTEK SWEDEN AB is not obligated to any other warranty
other than this warranty.
FLOAT
5
4
13.6V
0.8A
10 days
3 minutes
Charge cycle restarts
if voltage drops
PULSE
stEP 1 dEsuLPhAtiON
Detects sulphated batteries. Pulsing current
and voltage, removes sulphate from the
lead plates of the battery restoring the
battery capacity.
stEP 2 BuLK
Charging with maximum current until
approximately 80% battery capacity.
6
stEP 3 ABsORPtiON
Charging with declining current to maxi-
mize up to 100% battery capacity.
stEP 4 ANALysE
Tests if the battery can hold charge. Batter-
ies that can not hold charge may need to
be replaced.
stEP 5 fLOAt
12.7V‒14.4V
0.8‒0.4A Maintaining the battery voltage at
maximum level by providing a constant
voltage charge.
Charge cycle restarts
if voltage drops stEP 6 PuLsE
Maintaining the battery at 95–100%
capacity. The charger monitors the battery
voltage and gives a pulse when necessary
to keep the battery fully charged.
