HCL Smart Band SM-FT-1000 Operation, Parts And Safety Manual

Banding tool
Hide thumbs Also See for Smart Band SM-FT-1000:
Table of Contents

Advertisement

Quick Links

Download this manual
Registered
©2009 HCL Fasteners
Operation, Parts and
Safety Manual
TOOLING
SM-FT-1000
Banding Tool
Suitable for Smart Band® 32mm (1¼") 25mm (1")
19mm (¾") and Smart Tie™ 20mm (¾")
READ ALL INSTRUCTIONS BEFORE OPERATING THIS
HCL PRODUCT
IMPORTANT – DO NOT DESTROY
It is the customer's responsibility to have all operators
and servicemen read and understand this manual.
For additional copies please contact HCL.
NOVEMBER 2009

Advertisement

Table of Contents
loading

Related Manuals for HCL Smart Band SM-FT-1000

Summary of Contents for HCL Smart Band SM-FT-1000

  • Page 1 READ ALL INSTRUCTIONS BEFORE OPERATING THIS HCL PRODUCT IMPORTANT – DO NOT DESTROY It is the customer’s responsibility to have all operators and servicemen read and understand this manual. For additional copies please contact HCL. Registered ©2009 HCL Fasteners NOVEMBER 2009...
  • Page 2 Operation, Parts and Safety Manual TOOLING 1 Warning & Safety Instructions 2 Introduction 3 Operation 4 Tensioning Tables 5 Pressure Regulation 6 Maintenance 7 Adapting the Tool 8 Trouble Shooting 9 Parts List ©2009 HCL Fasteners NOVEMBER 2009...

  • Page 3: Strap Breakage Hazard

     F ailuretoplacethestrapproperlyaroundtheload,anunstableor shiftedload,couldresultinasuddenlossofstraptensionduring tensioning.Thiscouldresultinasuddenlossofbalancecausing youtofall.  P ositioningyourselfin-linewiththestrapduringtensioning,can resultinpersonalinjuryfromflyingstraportool.Whentensioning, positionyourselftoonesideofthestrapandkeepallbystanders away. 2. TRAINING  T histoolmustnotbeusedbypersonsnotproperlytrained initsuse.Becertainthatyoureceivepropertrainingfrom youremployer.IfyouhaveanyquestionscontactyourHCL representative. 3. EYE INJURY HAZARD  F ailuretowearsafetyglasseswithsideshieldscanresultineye injuryorblindness.Alwayswearsafetyglasseswithsideshields whichconformtoANSIStandardZ87.1orEN166. 4. FALL HAZARD M aintainingimproperfootingand/orbalancewhenoperatingthe toolcancauseyoutofall.Donotusethetoolwhenyouareinan awkwardposition. 5. CUT HAZARD A lthoughtheSmartBand®isnotmetallicandtherefore significantlylesslikelytocausecutstohandsorfingersitisstill stronglyrecommendedthattheoperatorwearprotectivegloves.
  • Page 4 TORQUE WRENCH SM-FT-1000 Banding Tool MAIN FITTING TOOL Depending on set up, this power tool is designed to assemble HCL Smart Band® 32mm (1¼”), 25mm (1”), 19mm (¾”) or Smart Tie™ 20mm (¾”) WATERPROOF CASE Systems. Follow the instructions described to achieve safe operation.

  • Page 5: Operation

    B A N D I N G T O O L I N G S E C T I O N Operation Initial fitting and tightening Insert band into fixed end of the buckle TEETH ENGAGED Pull back band to engage latch WARNING –...
  • Page 6 S E C T I O N B A N D I N G T O O L I N G Pull band tight by hand, making sure teeth are fully engaged with band Ensure that green marker is showing Insert tool onto band Push tool up against buckle SM-FT-1000 Banding Tool...
  • Page 7 B A N D I N G T O O L I N G S E C T I O N For manual tightening attach handle to the square drive at the rear of the tool WARNING – Ensure tool does not lift away from application during tightening Wind handle clockwise until...
  • Page 8 ..S E C T I O N B A N D I N G T O O L I N G Refer to Section 4 Tensioning Tables to set the correct pressure. Hold down trigger on air ratchet. The tool will stall when the system reaches the correct tension.
  • Page 9 B A N D I N G T O O L I N G S E C T I O N Tensioning Tables WARNING – Do not exceed the maximum pressure or torque settings recommended for the Smart Tie™ or Smart Band® system being applied Pressure Conversion Triangle (N/mm x 0.006895...

  • Page 10: Pressure Regulation

    S E C T I O N B A N D I N G T O O L I N G Pressure Regulation Pressure Regulator Gauge Air Filter – ” BSP female input Pressure Regulator Knob Air Lubricator Lubrication Dial Lubrication Fill-point Lockable Shut-Off Valve 5m hose...

  • Page 11: Maintenance

    B A N D I N G T O O L I N G S E C T I O N Maintenance For maintenance of air ratchets please see manufacturers manual TOOL BACK Remove M4 Capscrews and Full nuts (4x each) from split housing.
  • Page 12 S E C T I O N B A N D I N G T O O L I N G Example of a 19mm (¾”) Adapting Adaptation Kit the Tool Every fitting tool can be adapted to fit the following sizes of Smart Band: 32mm (1¼”), 25mm (1”) &...

  • Page 13: Troubleshooting

    B A N D I N G T O O L I N G S E C T I O N Trouble Shooting Symptom 1: Inadequate Band Tension Possible Cause Solution 1. Tool has hit rear stop (red marker showing) Wind square drive anti-clockwise until green marker is showing.

  • Page 14: Parts List

    S E C T I O N B A N D I N G T O O L I N G Parts List ITEM PART NUMBER DESCRIPTION QTY. BUTTONHEAD SCREW, SKT HD, BHS_M8X10_SS M8x10LG, SS BLB_3_7_3_SS BEARING, BALL ROLLER, 3IDx7ODx3LG CPS_M4X16_SS CAPSCREW, SKT HD, M4x16LG, SS ITEM...

  • Page 15: Declaration Of Conformity

    Your attention is drawn to the following: HCL warrants that a new HCL banding tool will operate per functional specifications for a period of sixty (60) days after the date of shipment to the owners place of business. Normal wearing parts, as outlined in the Operations, Parts & Safety manual, are also covered by a sixty (60) day warranty unless, in HCL’s judgement, these parts have been subjected to abnormal or extreme usage.
