Dimensions • Abmessungen • Encombrement • Dimensiones • Dimensioni • Dimensões
5897
Note: Reference dimensions in mm
Hinweis: Bezugsmaße in mm
Remarque : cotes de référence en mm
Nota: Dimensiones de referencia en mm
Nota: Dimensioni di riferimento in mm
Nota: As dimensões de referência são indicadas em mm
3797
3626
o
20
4420
2337
4940
4420
8077
9754
9
3556 RET
6020 MID
8484 FULL
R4361
4172
o
17
