Dahua ITC231-RF1A-IR User Manual page 76

Parameter Function
MAC address Display host MAC address.
IP version Select IP version IPV4 or IPV6. These two IP addresses both can be accessed.
IP address Input new IP address to edit, and set subnet mask and default gateway.
Subnet Mask Device IP address corresponding subnet mask.
Default
Device IP address corresponding default gateway.
Gateway
Preferred DNS DNS server IP address.
Alternate DNS DNS server alternate IP address.
6.5.3.2 Connection
6.5.3.2.1 Connection
Set port parameters.
Parameter
Max Connection
TCP Port
UDP Port
HTTP Port
HTTPs Port
6.5.3.2.2 ONVIF User
ONVIF is Open Network Video Interface Forum, an online video to achieve a framework agreement,
which are produced by different vendors of network video products (such as front-end cameras, video
equipment, etc.) is fully interoperable.
Check the open ONVIF login, login ONVIF need a username and password verification; turn off the
feature you do not need validation. See
Note
Max connection（1~10）
Set TCP port （1025~65535）
Set UDP port（1025~65535）
Set HTTP port
Set HTTPs port
Figure 6-59 ONVIF
Chart 6-24
Chart 6-25
.
