HDCVI Fisheye Camera
User's Manual
V1.0.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Pro DH-HAC-EW2501 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Dahua Pro DH-HAC-EW2501

  • Page 1 Questo manuale d’istruzione è fornito da trovaprezzi.it. Scopri tutte le offerte per Dahua Pro DH- HAC-EW2501 o cerca il tuo prodotto tra le migliori offerte di Videosorveglianza HDCVI Fisheye Camera User’s Manual V1.0.0...
  • Page 2: Regulatory Information

    Regulatory Information The regulatory information herein might vary according to the model you purchased. Some information is only applicable for the country or region where the product is sold. FCC Information CAUTION Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
  • Page 3: Foreword

    Foreword General This user’s manual (hereinafter referred to be "the Manual") introduces the functions, installation, and operations of the camera. Safety Instructions The following categorized signal words with defined meaning might appear in the Manual. Signal Words Meaning Indicates a medium or low potential hazard which, if not avoided, WARNING could result in slight or moderate injury.
  • Page 4 regions. For detailed information, see the paper manual, CD-ROM, QR code or our official website. If there is inconsistency between paper manual and the electronic version, the electronic version shall prevail.  All the designs and software are subject to change without prior written notice. The product updates might cause some differences between the actual product and the Manual.
  • Page 5: Important Safeguards And Warnings

    Important Safeguards and Warnings Electrical Safety  All installation and operation should conform to your local electrical safety codes.  The power source shall conform to the requirement of the Safety Extra Low Voltage (SELV) standard, and supply power with rated voltage which conforms to Limited power Source requirement according to IEC60950-1.
  • Page 6 device is installed and maintained by professional engineers.  The surface of the image sensor should not be exposed to laser beam radiation in an environment where a laser beam device is used.  Do not provide two or more power supply sources for the device; otherwise it might damage the device.
  • Page 7: Table Of Contents

    Table of Contents Regulatory Information ..........................I Foreword ..............................II Important Safeguards and Warnings ....................IV 1 Introduction ............................1 1.1 General............................1 1.2 Features ............................1 2 Design ..............................2 2.1 Dimension ............................. 2 2.2 Cable ............................. 2 3 Installation .............................. 4 3.1 Installing Model A ..........................
  • Page 8: Introduction

    Introduction General This series of products comply with the HDCVI standard and support the transmission of video and control signal over coaxial cable. They produce video signal with megapixel resolution and require XVR device that comply with the HDCVI standard to achieve high speed, long distance, and zero lag transmission of the signal.
  • Page 9: Design

    Design Dimension Figure 2-1 Model A (mm [inch]) Figure 2-2 Model B (mm [inch]) Cable Cable type might vary with different cameras, and the actual product shall prevail. Design 2...
  • Page 10 Figure 2-3 Cable port list For more information about cable ports, see Table 2-1; for the operation method of ④ (DIP switch), see Table 2-2. Table 2-1 Cable port description Port Name Function Inputs 12V DC power. Please be sure to supply power as instructed in the Manual.
  • Page 11: Installation

    Installation Make sure the mounting surface is strong enough to hold at least three times of the  camera weight.  Keep the protection film on the dome before installation and adjustment finished to avoid possible scratch.  Properly handle the device after unpacking. Do not expose the device in humid environment.
  • Page 12 Step 3 Slide to unlock the buckle on the mounting plate③. See Figure 3-2. Figure 3-2 Unlocking mounting plate Step 4 Pull the device cable out through mounting surface or the cable tray on the bottom of the device. Step 5 Align the cable outlet holes on the device and the mounting plate, and then push to attach the device to the mounting plate.
  • Page 13: Installing Model B

    Installing Model B Figure 3-5 Model B installation Table 3-2 Installation item list Item Item Item Item ① ② ③ ④ Mounting surface Positioning map Expansion bolt Pedestal — — ⑤ ⑥ ⑦ Self-tapping screw Dome Locking screw Step 1 Drill screw holes (and the cable outlet hole if it needs to go through the mounting surface) on the mounting surface①...
  • Page 14: General Configuration

    General Configuration Power up the camera and connect it to XVR device with coaxial cable, and then the live view screen is displayed. The following instructions will guide you to configure your camera.  The number of the coaxial port on XVR will display at the lower left corner of each window to indicate the corresponding camera.
  • Page 15: Setting Audio Input

    Figure 4-2 Main menu Right-click anywhere on the screen to return to the previous interface until it goes back to live view screen. Setting Audio Input Audio signal acquisition is available on select models. Step 1 In the Main Menu interface (Figure 4-2), select CAMERA > ENCODE > Encode. The Encode interface is displayed.
  • Page 16: Operating Osd Menu

    Step 3 In the Main Stream column, click More Setting. The More Setting interface is displayed, see Figure 4-4. Figure 4-4 More setting Step 4 In the More Setting interface, you can configure the audio settings. Enable Audio Encode function. ...
  • Page 17 The MENU OPERATION panel is displayed. See Figure 4-7. The OSD menu of the corresponding camera is displayed on the live view screen. Figure 4-7 Menu operation panel For functions of the buttons in the MENU OPERATION panel, see Table 4-1. Table 4-1 Menu operation panel function Button Function...
  • Page 18: Maintenance

    Maintenance In order to maintain the image quality and proper functioning of the device, please read the following maintenance instructions carefully and hold rigid adherence. Disassembly and Desiccant Replacement Carefully follow the instructions in the manual when performing any disassembly operation ...
