Dahua Intelligent Traffic HD Camera
User's Manual
For ITC231-RF1A-IR
Version 1.0.0
ZHEJIANG DAHUA VISION TECHNOLOGY CO.,LTD.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ITC231-RF1A-IR and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Dahua ITC231-RF1A-IR

Summary of Contents for Dahua ITC231-RF1A-IR

  • Page 1 Dahua Intelligent Traffic HD Camera User’s Manual For ITC231-RF1A-IR Version 1.0.0 ZHEJIANG DAHUA VISION TECHNOLOGY CO.,LTD.
  • Page 2 Cybersecurity Recommendations Mandatory actions to be taken towards cybersecurity 1. Change Passwords and Use Strong Passwords: The number one reason systems get “hacked” is due to having weak or default passwords. It is recommended to change default passwords immediately and choose a strong password whenever possible.
  • Page 3 surveillance system. Using a different username and password for your security system will make it more difficult for someone to guess their way into your system. 9. Limit Features of Guest Accounts: If your system is set up for multiple users, ensure that each user only has rights to features and functions they need to use to perform their job.
  • Page 4 This user’s manual (hereinafter referred to be "the Manual") introduces the functions and operations of the ITC devices (hereinafter referred to be "the Device"). Models ITC231-RF1A-IR Safety Instructions The following categorized signal words with defined meaning might appear in the Manual.
  • Page 5 About the Manual  The Manual is for reference only. If there is inconsistency between the Manual and the actual product, the actual product shall govern.  All the designs and software are subject to change without prior written notice. The product updates might cause some differences between the actual product and the Manual.

  • Page 6: Important Safeguards And Warnings

    Important Safeguards and Warnings Electrical safety All installation and operation here should conform to your local electrical safety codes.  The product must be grounded to reduce the risk of electric shock.  We assume no liability or responsibility for all the fires or electrical shock caused by improper handling or installation.

  • Page 7: Table Of Contents

    Table of Contents Cybersecurity Recommendations ..................II Foreword ..........................IV Important Safeguards and Warnings ..................i General Introduction ...................... 1 Overview ......................1 Features ......................1 Device Structure ......................3 Rear Panel ......................3 Side Panel ......................5 Front Panel ....................... 5 Installation ........................
  • Page 8 Guide ......................22 6.3.1 Plate-pixel Check ..................23 6.3.2 Trigger Mode .................... 24 6.3.3 Lamp Config ..................... 26 6.3.4 Lane Property ................... 28 6.3.5 Complete ....................29 Query ......................29 6.4.1 Picture Query .................... 29 6.4.2 Flow Query ....................32 6.4.3 Record Query ...................

  • Page 9: General Introduction

    1 General Introduction 1.1 Overview Intelligent Traffic HD IR ANPR camera as the core monitoring device in a road monitoring system, adopts embedded operating systems, advanced compression technology H.265 encoding, flexible snapshot. The product monitors different roads, and sends the video data to client, server, back-end storage devices through the network.
  • Page 10  Support web access, widely used in WAN.  Dock with signal device to count traffic flow. Vehicle Flow Statistics  Picture snapshot and encode.  Watermark on picture.  User can set speed limit and interval of snapshot. Snapshot ...

  • Page 11: Device Structure

    2 Device Structure 2.1 Rear Panel Figure 2- 1 Interface Name Function This interface must be grounded, to improve device reliability, otherwise the device may lose lighting protection. STATUS Status indication It is to indicate camera working status:  light The blue light flashes when recording.
  • Page 12 Interface Name Function RS485_B1 interface，this device is used to control NO light, and others may expand to customize signal detector, vehicle detector and etc. RS485_A2 interface, this camera is used to control 485 focus lens, expand to customize other 485 control peripheral, such as external NO light.

  • Page 13: Side Panel

    Chart 2-1 2.2 Side Panel Figure 2- 2 2.3 Front Panel Figure 2- 3...

  • Page 14: Installation

    3 Installation Warning: To ensure the device is normally grounded and improve device reliability, please connect port of device to the ground. Figure 3- 1 3.1 Install Lens Figure 3- 2...

  • Page 15: Install Auto Iris Lens

    3.1.1 Install Auto Iris Lens Step 1. Remove the Sensor protective cover on the device. Step 2. Aim the lens at the mounting position of the lens on the camera, rotate the lens clockwise until it is securely in place. Step 3.

  • Page 16: Remove Tf Card

    Figure 3- 4 Install the TF card into the camera according to the proper installation position. 3.2.2 Remove TF card Figure 3- 5 Follow the TF card direction to remove the TF card from the device.

  • Page 17: I/O Port

    3.3 I/O Port Figure 3- 6 3.3.1 Install Cable Step 1. Use the small slotted screwdriver to press the corresponding button of cable groove. Step 2. Insert the cable into the groove. Step 3. Release the screwdriver. 3.3.2 Remove Cable Step 1.

  • Page 18: System Network

    4 System Network Figure 4-1 Please refer to Figure 4-1 Figure 4-2...

  • Page 20: Quick Configuration Tool

    5 Quick Configuration Tool By downloading and sign in Dahua Tool, you can get Quick Config Tool. Quick configuration tool can search current IP address, modify IP address. At the same time, you can use it to upgrade the device.

  • Page 21: Upgrade Device

    Step 3. Select device to modify IP.  Single: Click of target device to change its IP.  Batch modify: select device to change its IP, and click Modify IP. Step 4. Set mode, IP, subnet mask and gateway. Note: When you modify IP, select “Same IP”...
  • Page 22 Figure 5-3 Step 3. Select device to upgrade.  Single: click “Browse” of device you want to upgrade.  Batch: select device you want to upgrade, and click “Batch Upgrade”. Figure 5-4 Step 4. Select upgrade file, see...

  • Page 23: Login Web

    Figure 5-4 Step 5. Upgrade device.  Single: click “Upgrade”, and system shows progress.  Batch: click OK so system starts to upgrade. Note: During upgrading, as long as ConfigTool stays in upgrade interface, when device connects again, the upgrading will continue. 5.3 Login WEB ...

  • Page 24: Search Setting

    Figure 5-5 5.4 Search Setting Click , search device. Figure 5-6  Current Segment Search: select it, search device in the same segment with PC.  Other segment search: select it, search device by start IP and end IP.

  • Page 25: Web Operation

    6 Web Operation 6.1 Intro to WEB Note: Different devices and different versions of WEB may have different interface, please subject to actual models. 6.1.1 First Time Login Please follow the steps listed below for network connection. Step 1. Make sure the HD intelligent traffic camera has connected to the network properly. Connect Ethernet cable into PC port, and connect the other end of cable to device port.
  • Page 26 Step 5. After you have logged in for the first time, enter config wizard to change your password. Warning: For security reason, please change initial password. Figure 6-2 Step 6. Modify password and click Next, you can enter WEB homepage. Note: ...

  • Page 27: Non-First Time Login

    Figure 6-4 6.1.2 Non-First Time Login Step 1. In IE enter device IP address, click Enter. Step 2. Enter username and password, click Login. Figure 6-5 When you enter wrong username of password, you can see . If you have enter wrong username or password for 5 consecutive times, the account will be locked for 5 minutes.

  • Page 28: Live

    Function Note Live Introduces video and image window, record video and image setup and etc. Playback Introduce how to play system storage record file. Search Introduce different types of picture and record search, and watermark. Setup Introduce camera basic setup, ITC rule, protocol and etc. Alarm Introduce alarm prompt operation.

  • Page 29: Preview Window Switch

    Extra stream It is a substitute for main stream under insufficient band width. Protocol Select video monitoring protocol, currently support TCP only. Fluency Select video fluency. Chart 6-2 6.2.2 Preview Window Switch Figure 6-9 Preview Window Switch The preview window switch interface is shown as in Figure 6-9 Preview Window Switch ...

  • Page 30: Monitor Window Switch

    Manual Click on the button to snapshot. Snapshots are saved based on setup in “Setup->Camera->Video->Path”. snapshot Note: Check Receive Pictures and then snapshot picture and vehicle info will be shown in Live interface. Zoom in Click on the button to zoom in any area with left mouse. Right click mouse or click to exit.

  • Page 31: Plate-Pixel Check

    Figure 6-12 6.3.1 Plate-pixel Check Check vehicle plate pixel and confirm pixel of snapshot plate. Figure 6-13 Step 1. Click ”snapshot” to snapshot picture when the vehicle plate run into the green area (detection area). Step 2. Moving the small rectangle box to cover the area of plate.

  • Page 32: Trigger Mode

    Step 3. Click “zoom” to zooming the picture, please check the size of vehicle plate is between the inner edge and outer edge of rectangle.(if size no matching, the pixel of plate must be not easy for recognize , please change the lens or the angle of camera) Figure 6-14 6.3.2 Trigger Mode Figure 6-15...
  • Page 33 Figure 6-15 Step 1. Select config line you want to draw. Step 2. Draw line within visible range. Note:  Click Redraw to delete current config line.  In lane direction select head or rear to quickly switch lane direction. Parameter Note Both indicator direction of vehicle, but algorithms are different.

  • Page 34: Lamp Config

    Parameter Note Used to verify accuracy of calibration result. Click “C Check”, draw line in the area and it shows actual length. C Check Click “Redraw” to delete original line. Chart 6-4 Step 3. After lane line is drawn, it auto shows lane info. You can modify or delete current Lane Line. ...
  • Page 35 Figure 6-17 Parameter Note COM1, COM2 Select serial according to actually connected port A and B. Light Type You can select small or big light. CheckStatus Select to enable detection status of external light. Select work mode, include：  Turn off：NO light always off Work Mode Turn on：NO light always on ...

  • Page 36: Lane Property

    Chart 6-6 6.3.4 Lane Property Set lane info and configure event. Figure 6-18 Parameter Note Lane Property Select lane you want to enable its snapshot, here no. correspond to Snap Enable physical lane. Roadway Code Fill in roadway code. Route Code Fill in router code.

  • Page 37: Complete

    Chart 6-7 6.3.5 Complete View camera version and work mode after config. Figure 6-19 6.4 Query 6.4.1 Picture Query 6.4.1.1 SD Card Picture Figure 6-20 Picture Query Click query button, you can see an interface is shown as in Please select start time, end time, and event type. Then please click search button, you can see the corresponding files in the list.
  • Page 38 Figure 6-20 Picture Query Please refer to the following sheet for detailed information. Parameter Function Start time Set start time of picture to search. End time Set end time of picture to search. Event type Search by violation event type. Vehicle Sign Select, it searches picture by logo.
  • Page 39 Step 2. Select the need to download images from the file list, click "Download." Step 3. In the pop-up picture Save dialog box, set the image saving path, start the system image is downloaded to the local PC. 6.4.1.2 Picture Attribute According to need of download pictures, setting qualifying picture information, click "Help ..."...

  • Page 40: Flow Query

    Help  View naming rule. Chart 6-9 6.4.1.3 PC Picture Click "Open local ", select the required check image, click "Watermark check" to see the check results in the pictures list. Select the picture and click "Open" to preview the image. Figure 6-22 Search Local Picture Step 1.

  • Page 41: Record Query

    Figure 6-23 Step 1. Set start time and end time for search. Step 2. Click Search, click Backup to back up to local PC. Click Clear to view result. 6.4.3 Record Query 6.4.3.1 Record Figure 6-24 Record Query Click record query, you can see an interface is shown as in...
  • Page 42 Figure 6-24 Record Query 6.4.3.2 Watermark Note: Users are required to use this function in "Settings> Camera Settings> Video" section, select the watermark settings enabled, set the corresponding watermark character, the default watermarks characters: DigitalCCTV. Select the video file, click the "Watermark check", the system displays the checksum progress,...

  • Page 43: Configure

    Figure 6-25 Watermark Step 3. After completion, the page shows watermark is finished. 6.5 Configure 6.5.1 ITC 6.5.1.1 Lane Property User shall set related parameter according to their need. ANPR device need different config of event. Figure 6-26 Select Setting>ITC>Lane Property, see...
  • Page 44 Figure 6-26 Please refer to the following sheet for detailed information. Parameter Function Lane Property Enable snapshot Select lane to enable. The no. corresponds to actual lane no. Related Record Check the "related record", the time will be illegal to capture video, set the length of recording time as shown in figure.
  • Page 45 Customized lane no. Set different no. for each lane. Direction Select lane direction to snapshot. Default is general lane. Car Way Type Set lane direction. Road Direction Event Note: Different lane types correspond to different event type. ANPR Select snapshot ANPR vehicle. Retrograde Choose whether to capture retrograde vehicles.
  • Page 46 Figure 6-27 Parameter Note Set illegal parking time to trigger this event. When a vehicle illegally Trigger Time（s） parks over this time, it will trigger snapshot. Parking Time（s） Set time length of vehicle illegal parking snapshot. Illegal Name Fill in violation name. Illegal Code Set corresponding code of violation type.
  • Page 47 Figure 6-28 To set time period: Step 1. Select week day or click Setting. Step 2. Select period no. to enable, and manually enter start time. Step 3. Click Yes. 6.5.1.2 Snapshot Set max speed, match method and location mode of snapshot. Figure 6-29 Snapshot The snapshot interface is shown as in...
  • Page 48 Figure 6-29 Snapshot Please refer to the following sheet for detailed information. Parameter Note When it detects vehicle speed over this value, system will auto fix Max Speed vehicle speed to random value within normal speed range. Snap Position Mode Set camera snapshot location, either fixed or auto mode.
  • Page 49 Figure 6-30 Video Analysis-ANPR Step 2. Select line you want to draw. Step 3. In video, draw out the line. Note:  Click Redraw to delete current config line.  In lane direction, select head or rear to quickly switch lane line direction. Please refer to the following sheet for log parameter information.
  • Page 50 Detect line  Draw border line to trigger snapshot which is similar to actual coil. When vehicle reach this line, snapshot will be triggered. Detect line is available inside drawn region only.   Select and click on redraw to drawn region as red box in Figure 4-8. When you select front, lane arrow is downward.
  • Page 51 Figure 6-32 Light Group Click on setup enter light group config interface to set parameter. Please refer to the following sheet for log parameter information. Parameter Note Camera height from the ground H Actual height from camera to the ground Distance camera &...
  • Page 52 Figure 6-33 Recognition Please refer to the following sheet for log parameter information. Parameter Function Car Series Detect Recognize vehicle series of different brands. Vehicle Sign Recognize vehicle brand. Sun Shade Detect Recognize if driver uses sun shade.  Vehicle Type Choose the parameter, you can identify the vehicle type.
  • Page 53 Figure 6-34 Advance Config Please refer to the following sheet for log parameter information. Parameter Note Advanced Options You can enter a custom algorithm expression, implement special features custom. Chart 6-17 6.5.1.4 OSD Config 6.5.1.4.1 Video OSD Figure 6-35 Video OSD Set video channel OSD.
  • Page 54 Figure 6-35 Video OSD Step 2. Select Front Size. Step 3. Set time title and position. Select channel title. Select Turn on. In Input Channel Title, enter channel name. Use mouse to drag yellow box or enter coordinate directly, set channel title position. Set time title and position.
  • Page 55 Figure 6-36 Snap OSD Step 2. Select any position in the video and drag mouse, you can add picture title. Move box to place you want to show the title, or enter coordinate below to position the box. You can enter up to 8 picture title, and each title has OSD option. Note: Select one picture title, right-click, you can delete the picture caption.
  • Page 56 Step 6. Set OSD option. Tips: Click Suggest Overlay to quickly set common overlay format. Parameter Note Insert Front OSD option to adjust the order selected between. Insert Back OSD option to adjust the order selected between. Modify All selected OSD information state by turns , you can modify any OSD options prefix, suffix, and other content, and the number of...
  • Page 57 Select Setting>ITC>Extra Device>Extra Device Status, Figure 6-39 Extra Device The extra device interface is shown as in . Here you can view aux device type, no. and status. Figure 6-39 Extra Device 6.5.1.6.2 Light (485) Config Set steady lamp, frequency lamp work mode via 485. Select Setting>ITC>Extra Device>Light 9485) Config.
  • Page 58 Figure 6-40 Parameter Note COM 1, COM According to actual connected port A, B and select serial. Light Type Select small or big lamp Select work mode, include： Forbidden：NO always OFF.  Work Mode Always：NO always ON.   Default：According to time or brightness, auto turn ON or OFF. Check Status Select to check status of light.
  • Page 59 Parameter Note Brightness Value. Prevalue Note: Auto work mode only, and Brightness is selected. Auto light on time. Time Settings Note: Auto work mode only, and Time is selected. Chart 6-18 6.5.1.7 BW List 6.5.1.7.1 White List Select Setup>ITC>BW List. ...
  • Page 60 View vehicle details. Import/Export white list vehicle info. Figure 6-42 Functions:  Search plate no.  Edit plate info  Delete single plate no.  Batch delete plate no. Chart 6-20 For example, the system import data, see Master Plate Plate Plate Vehicle...
  • Page 61  Progressively import white list info Steps: Figure 6-43 Step 1. Click Add. See Figure 6-43 Step 2. Enter complete plate character. Step 3. Set start time and end time of its existence in white list. Once exceeding this period, the plate will no longer be in white list.
  • Page 62 Step 3. In Export form, follow format of the first white list item, fill in other white list items you want to import, save. Step 4. Click Brose, select path, click Import.  Batch export white list: click Export, in pop-up box click Save. Select path and click save. 6.5.1.7.3 Black List Data Select Setup>ITC>BW List>Black List Search.
  • Page 63 Figure 6-45 Step 2. Set period. Step 3. Set flow lane. Step 4. Select Enable. Step 5. Click OK. 6.5.1.8.2 Flow Data Figure 6-46 Select Setting>ITC>Traffic Flow>Flow Data, see Figure 6-46...
  • Page 64  Click a row, to view corresponding period and lane detailed info.  Click to delete current flow data.  Click Export to export current flow data to local. 6.5.1.9 Device Direction 6.5.1.9.1 Device Direction Figure 6-47 Select Setting>ITC>Device Direction>Device Direction, see It shows info gotten from GPS or BeiDou system.

  • Page 65: Camera

    Figure 6-48 6.5.1.10 Intelligence Default Figure 6-49 Intelligence Default The intelligence default interface is shown as in Click on default to restore default settings. Figure 6-49 Intelligence Default 6.5.2 Camera 6.5.2.1 Attribute 6.5.2.1.1 General Figure 6-50 General The general interface is shown as in .
  • Page 66 Figure 6-50 General Please refer to the following sheet for log parameter information. Parameter Function The value adjusts brightness of full image. Default value is 50. The higher the value, Brightness the brighter the image. When image is too bright or too dark, you may adjust this value.
  • Page 67 Parameter Function ICR switch：  Auto：Automatically switch according to the brightness ICR Switch  General：Normal operation  CPL：Night filter switching equipment Chart 6-21 6.5.2.1.2 Shutter Figure 6-51 Shutter The shutter interface is shown as in Select Setting>Camera>Attributes>Shutter. Figure 6-51 Shutter Please refer to the following sheet for log parameter information.
  • Page 68 Exposure mode Select exposure mode: auto and manual. You can set manual exposure mode as 1/50～1/10000. You may also customize. Scene mode Set scene mode according to device environment.  Disabled：disable scene mode.  Default ： select Full Auto, High Color Temperature, Low Color Temperature, Auto Color Temperature or Partial Auto.
  • Page 69 Parameter Note Iris Type Select current lens to use. Select iris adjust method. Different lens types have different adjustment of iris. Iris Adjust Mode  Default: auto adjust.  Manual: manually adjust. Chart 6-22 6.5.2.1.4 Metering Zone Figure 6-53 Metering Zone The metering zone interface is shown as in Select Setting>Camera>Attributes>Metering Zone.
  • Page 70 6.5.2.1.5 Focus This is auto focus function, and you can one-click complete adjustment. Step 1. Setting>Camera>Attributes>Focus. Figure 6-54 Figure 6-54 Step 2. Drag the bar to see speed size. Step 3. Click dropdown list below Speed, set ABF speed. The higher the value, the faster the speed will Step 4.
  • Page 71 Figure 6-55 Video Please refer to the following sheet for log parameter information. Parameter Function Code-stream Support only general stream. type Encode mode It supports H.264B, H.264M, H.264H, MJPEG and H.265. Resolution Display resolution, which differ according to camera model. Frame rate Different model supports max FPS.
  • Page 72 Parameter Function Enable Control the secondary stream is turned on. The default is not open. Code Stream General stream. Type Encode Mode Currently only supports H.264B, H.264M, H.264H, MJPEG, and H.265. Currently it supports up to UXGA, 720P, D1, CIF. Resolution Note: Sub stream cannot exceed main stream.
  • Page 73 Figure 6-56 Snapshot Please refer to the following sheet for log parameter information. Parameter Function Snapshot It includes general snap and trigger snap. General snap works within type predetermined time period. Trigger snap works at time of motion detect, privacy masking and relay activation.

  • Page 74: Network

    Figure 6-57 Interest Area Please refer to the following sheet for log parameter information. Parameter Function  Image You may drag left mouse to set interest area. quality  Select snap quality from 6 levels. Remove  Click it to delete all set area. ...
  • Page 75 Figure 6-58 TCP/IP Please refer to the following sheet for log parameter information. Parameter Function Host name Set current host name. Max supports 32 characters. Set Ethernet card to config. Default is wired. Note: For model with –W, you can use wireless Ehternet card and edit card. You Ethernet card must reboot device if you have set default card.
  • Page 76 Parameter Function MAC address Display host MAC address. IP version Select IP version IPV4 or IPV6. These two IP addresses both can be accessed. IP address Input new IP address to edit, and set subnet mask and default gateway. Subnet Mask Device IP address corresponding subnet mask.
  • Page 77 Figure 6-59 ONVIF 6.5.3.3 Auto Register Enable auto register function. When the device connects to WAN, it will reports user position to specified server periodically, so client software can access device, preview and monitor via server. Figure 6-60 Select Setting>Network>Auto Register, see Figure 6-60 Parameter Note...
  • Page 78 In HTTPS setup interface, a user can make PC pass HTTPS by creating certificate or upload signed certificate. Create Customized Certificate and Install Figure 6-61 Step 1. Select Setting>Network>HTTPS. See Figure 6-61 Step 2. Create certificate. Step 1. Click Create, see...
  • Page 79 Figure 6-62 Step 2. Set HTTPS parameter, see Parameter Note Country Initial of country name. Two upper cases only. IP or Domain name Device IP address. Validity Certificate validity. Province Province of certificate usage Location Location of certificate usage Organization Organization of certificate usage Organization Unit Organization name of certificate usage...
  • Page 80 Figure 6-63 Step 1. Double click , see Figure 6-63 Figure 6-64 Step 2. Click Install Certificate. See...
  • Page 81 Figure 6-64 Figure 6-65 Step 3. Click Next, see Figure 6-65...
  • Page 82 Step 4. Select Place all certificate in the following store, click Browse. Set Certificate to be “Trusted Root Certification Authorities”, and click Next. The following is wizard interface. Figure 6-66 Step 5. Click Finish. In pop up Security Warning box, click Yes. Then Click OK. Import is complete. Step 6.
  • Page 83 Figure 6-67 Click Certificate Path’s corresponding “Browse”, and select signed certificate file. Click Step 2. Certificate Key Path’s corresponding “Browse” to select key file of signed certificate. Step 3. Click Upload. The system starts to install certificate, and after complete, it generate property of the certificate in installation area.
  • Page 84 Figure 6-68 Click Install Certificate. See Figure 6-69.
  • Page 85 Figure 6-69 Click Next, see Figure 6-70. Figure 6-70...

  • Page 86: Event

    Select “Place all certificate in the following store”, click “Browse” and set “Certificate Store” to be “Trusted Root Certification Authorities”, click Next. Figure 6-71 Figure 6-71 Click Finish. In pop-up Security Warning box, click OK. And click OK again. Click OK. Step 6.
  • Page 87 Figure 6-72 Relay Activation Step 2. Select Enable. Step 3. Set alarm parameters. Please refer to the following sheet for log parameter information. Parameter Function Relay-in Support 2 channels of alarm input. Period Set alarm arm and disarm period. Click on setup button to open period menu. Anti-dither During anti-dither period, only one alarm will be recorded.
  • Page 88 Figure 6-73 Relay-out The relay-out interface is shown as in Step 1. Select Setting>Event>Alarm>Relay-out. Figure 6-73 Relay-out Step 2. Click 1, 2, or 3. Set 1 channel of alarm output. Step 3. Click trigger to output alarm signal. Step 4. Click Refresh to search alarm output status.
  • Page 89 Figure 6-75 Capacity Warning Figure 6-76 Storage Error Figure 6-77 Disconnection Figure 6-78 IP Conflict...
  • Page 90 Figure 6-79 Device Attitude Error Figure 6-80 Illegal Parking Please refer to the following sheet for log parameter information. Parameter Function Enable Check box to enable this function. Relay-out When alarm occurs, set corresponding relay out. You must enable this function first.
  • Page 91 Parameter Function Acceleration Set acceleration threshold, unit is degree. Threshold Chart 6-29 6.5.4.3 IVS Event 6.5.4.3.1 Pedestrian When it detects pedestrian in detection zone, it will trigger alarm. Figure 6-81 Step 1. Select Setting>Event>IVS Event>Pedestrian. See Figure 6-81 Step 2. Set parameters. Parameter Note Lane...
  • Page 92 Figure 6-82 Chart 6-31 Step 2. Set parameters, see Parameter Note Lane Select lane no. of detection zone. Snapshot Select to enable snapshot. Chart 6-31 Step 3. Click OK. 6.5.4.3.3 Retrograde Figure 6-83 Select>Event>IVS Event>Retrograde, see Figure 6-83 6.5.4.3.4 Jam When traffic jam occurs, it will trigger alarm.

  • Page 93: Storage

    Figure 6-84 Parameter Note Lane Select lane no. in detection area. Jam Range Percentage of jam Snapshot Select to enable snapshot Chart 6-32 6.5.5 Storage 6.5.5.1 Destination 6.5.5.1.1 Point Set storage of snapshot and record. Snapshot event has local storage and FTP. Record event has local storage.
  • Page 94 The list shows FT card info, and you can format it and select whether to overwrite or stop storage when disk is full. Figure 6-86 Local Select Setting>Storage>Destination>Local, see Figure 6-86 Local 6.5.5.1.3 FTP FTP: You must enable FTP before selecting it for current storage. When disconnection occurs or Figure 6-87 FTP malfunctions, it saves file or snapshot to local TF card.
  • Page 95 Figure 6-87 FTP Parameter Note When the network is disconnected or failed, you can save the image to the Offline Transfer local memory card, to be automatically restored after the network upload to the FTP server or platform. Server 1, Server 2, Support FTP upload, to upload event to different FTP servers.
  • Page 96 Chart 6-33 6.5.5.1.4 Client  Check the "Offline transfer", when the network is disconnected or faulty, you can save a picture to capture the local TF card, until the network is restored, the server automatically uploaded to the platform.  Upload by IP address or MAX address.
  • Page 97 Figure 6-89 Path 6.5.5.2 Record Control Select record mode and record stream. If you select Off for record mode, then you cannot link record. Figure 6-90 Record Control Select Setting>Storage>Record Control, select Automatic or Manual record, and select main stream or sub stream.

  • Page 98: System

    Figure 6-90 Record Control Parameter Note Record Mode select Automatic or Manual record or off. Record Stream select main stream or sub stream. Chart 6-34 6.5.6 System 6.5.6.1 General 6.5.6.1.1 General Figure 6-91 General The general interface is shown as in Figure 6-91 General...
  • Page 99 Please refer to the following sheet for log parameter information. Parameter Function Device SN Set the device number. Device Code Fill apparatus for encoding flag. Language Select language and then close IE. When you log in again, system language will change.
  • Page 100 Please refer to the following sheet for log parameter information. Parameter Function Date format Select date format. Time format Select time format. Current time Set current system time. Setup becomes effective immediately. Sync PC Sync system time with PC time. Click on save to refresh system time. Set DST, may by date or week.
  • Page 101 Figure 6-93 Username Anonymous login: Enable anonymous login as input IP without username and password to log in device. This type of account only have preview right. You may switch to other account by clicking on logout. Add user: Add user within group and set user right. By default there are three users: admin, 888888 and 666666.
  • Page 102 Figure 6-94 Modify User Modify user: Modify existing user’s group, password, right and note. Modify password: Modify password of existing user. Check box in front of modify password. Input current password and then input new password. Click on save. Password supports 0~15 characters, including letter and number only.
  • Page 103 Figure 6-95 Group Add group: Add user within group and set group right. Note:  You cannot delete admin and user groups.  You cannot delete group which contains currently logged in user. 6.5.6.2.4 ONVIF User Figure 6-96 ONVIF user is separated from device user, so could be managed alone, see Username Rule same as in Figure 6-96...
  • Page 104 Click , see Figure 6-97. Figure 6-97 6.5.6.3 Safety 6.5.6.3.1 SSH SSH is a protocol based on application and is reliable. SSD server is OFF by default, you can select SSH Enable to enable it. Figure 6-98 Figure 6-98 6.5.6.3.2 IP Filter You can add, delete Trust List and Banned List in IP Filter interface.
  • Page 105 Figure 6-99 6.5.6.4 Default Figure 6-100 Default The default interface is shown as in Figure 6-100 Default Note:  Network IP address, account info and system log cannot be restored to default.  Each parameter of camera will be restored to default. 6.5.6.5 Import/Export Figure 6-101 Import/Export The import/export interface is shown as in...
  • Page 106 Figure 6-101 Import/Export Step 2. Click Import or Export.  Import: import local backup file to system.  Export: export related config to local. Note: Import and export files are both in “.backup” format. Step 3. Select import file path or folder to export. 6.5.6.6 Auto Maintain Figure 6-102 Auto Maintain The auto maintains interface is shown as in...

  • Page 107: Information

    Figure 6-103 Upgrade The upgrade interface is shown as in Figure 6-103 Upgrade Note: If system encounters error during upgrading, the device may malfunction. 6.5.7 Information 6.5.7.1 Version Figure 6-104 Version The version interface is shown as in Select Setting>Information>Version, to view current WEB version. Note: Different device version has different info, subject to WEB.
  • Page 108 6.5.7.2 Log 6.5.7.2.1 Log The log interface is shown as in Figure 6-105 Log. The system supports filter by time, log type and etc. You can search log and back up log. Log type includes system operation, config operation, data operation, event operation, record operation, user management and safety management.
  • Page 109 Figure 6-106 Step 2. Select Enable to enable remote log function. Step 3. Enter log server IP address, port, device number. Step 4. Click OK. 6.5.7.3 Online User Figure 6-107 Online User The online user interface is shown as in .

  • Page 110: Alarm

    Figure 6-108 6.6 Alarm Figure 6-109 In WEB interface, open alarm setup, here you can set alarm type and prompt. See Figure 6-109 Type Parameter Note Storage Full When storage is full, trigger alarm Storage Error When storage has error, trigger alarm External Alarm Alarm input device alarm Alarm Type...

  • Page 111: Logout

    Type Parameter Note Parking Illegal parking , trigger alarm Retorgrade Retrograde, trigger alarm Pedstrain When pedestrian occurs, trigger alarm Illegal Access Detect illegal access, trigger alarm WEB subscribed alarm type selected above from device, and Operation Listen Alarm device will notify WEB by alarm and WEB notify users. Play Alarm Alarm has tone, you can customize alarm sound...

  • Page 112: Faq

    7 FAQ Solution I cannot boot up Please click RESET button for at least five seconds to restore the device. factory default setup. Before draw out TF card, please stop record or snapshot first and TF card hot swap then wait for at least 15 seconds to remove the TF card. All the operations before is to maintain data integrity.
  • Page 113 ZHEJIANG DAHUA VISION TECHNOLOGY CO.,LTD. No.1199, Bin'an Road, Binjiang District, Hangzhou, P.R. China Postcode: 310053 Tel: +86-571-87688883 Fax: +86-571-87688815 Email:overseas@dahuatech.com Website: www.dahuatech.com...
