Technical Specifications - Johnson Controls NS Series Installation Instructions

Technical Specifications

NS Series Network Discharge Air Sensors
Supply Voltage
Current Consumption
Terminations
Sensor Addressing
Wire Size
Communication Rate
Temperature Measurement
Range
Temperature Sensor Type
Temperature NS Series
Accuracy Discharge Air
Sensor
Temperature
Element Only
Ambient Operating
Conditions
Storage
Compliance BACnet®
International
United States
Canada
Europe
Australia and
New Zealand
Dimensions Sensor
Enclosure
(Height x
Width x Depth)
Temperature
Probe
Shipping NS-DTN7043-0
Weight
NS-DTN7083-0
The performance specifications are nominal and conform to acceptable industry standards. For application at conditions beyond these
specifications, consult the local Johnson Controls office. Johnson Controls, Inc. shall not be liable for damage resulting from misapplication or
misuse of its products.
Published in U.S.A.
9.8 to 16.5 VDC; 15 VDC Nominal
12 mA Maximum (Non-transmitting) per Discharge Air Sensor;
60 mA Maximum Total Current Consumption per SA Bus
Four Color-Coded Wiring Leads, Stripped and Tinned;
Factory-Installed at the Discharge Air Sensor Screw Terminal Block
DIP Switch Set (204 to 211); Factory Set at 204
1.0 to 0.6 mm (18 to 22 AWG) Diameter);
0.6 mm (22 AWG) Diameter Recommended; 305 cm (10 ft) Wiring Lead Included with the
Unit
Auto-Detect: 9.6k, 19.2k, 38.4k, or 76.8k bps
-10°C/14°F to 60°C/140°F
Local 1k Ohm Platinum Resistance Temperature Detector (RTD); Class A per IEC 60751
±0.6C°/±1.0F°
0.19C° at 21°C (0.35F° at 70°F)
-10 to 60°C (14 to 140°F); 10 to 90% RH, Noncondensing; 29°C (85°F) Maximum Dew
Point
-40 to 70°C (-40 to 158°F); 5 to 95% RH, Noncondensing
BACnet Testing Laboratories™ (BTL) 135-2004 Listed BACnet Smart Sensor (B-SS)
UL Listed, File E107041, CCN PAZX,
Under UL 916, Energy Management Equipment
FCC Compliant to CFR 47, Part 15, Subpart B, Class A
UL Listed, File E107041, CCN PAZX7,
Under CAN/CSA C22.2 No. 205, Signal Equipment
Industry Canada, ICES-003
CE Mark – Johnson Controls, Inc. declares that this product is in compliance with the
essential requirements and other relevant provisions of the EMC Directive 2004/108/EC.
C-Tick Mark, Australia/NZ Emissions Compliant
76 x 76 x 51 mm (3 x 3 x 2 in.)
NS-DTN7043-0: 102 mm (4 in.) Long
NS-DTN7083-0: 203 mm (8 in.) Long
0.52 kg (1.15 lb)
0.53 kg (1.17 lb)
