CYBEX IC1 Series Manual page 16

Re-check the amount of play in the belt
as described at the beginning of this
step. If necessary, readjust the belt.
Finally, retighten the two outer adjustment
nuts (C) and the two axle nuts (B), and
reattach the maintenance covers. To avoid
damage to the flywheel bearings, do not
over tighten the axle nuts (B). Unusual
noises or vibrations are indications that
the belt has been over tightened or
that the flywheel is at a wrong angle.
MAINTENANCE ACTIVITY REQUIRED SCHEDULE
ACTIVITY
FEET LEVELING, DISINFECTION & CLEANING OF THE BIKE
SERVICING BRAKE PADS,
DETAILED CLEANING OF THE ENTIRE BIKE
CHECK EMERGENCY BRAKE FUNCTION
CHECK BELT TENSION
Version 1.0 2017 IC-CYIC1B1-01 Copyright by Indoor Cycling Group GmbH 2017 | www.indoorcycling.com
PREVENTATIVE
MAINTENANCE
3.
C
ABOVE GRAPHICS SHOWS THE
RIGHT SIDE OF THE BIKE
ROTATION
DAILY
WEEKLY
BI-WEEKLY
MONTHLY
D
(RIDING POSITION)
PAGE
PAGE 14
PAGE 14
PAGE 15
PAGE 15-16
