  • Page 1 Operating instructions Ultrasonic retro-reflective sensor with IO-Link UGR500 UGR501...
  • Page 2: Explanation Of Symbols

    1 Preliminary note 1.1 Explanation of symbols ► Instructions > Reaction, result → Cross-reference Important note Non-compliance may result in malfunction or interference. Information Supplementary note. 2 Safety instructions • Read this document before setting up the product and keep it during the entire service life.
  • Page 3: Electrical Connection

    4: Teach button 5: Reflector The functional specifications refer to a mild steel reflector defined by ifm at maximum range and with an edge length of 300 mm. The minimum size of the reflector depends on the size of the object.
  • Page 4 The IODDs necessary for the configuration of the unit, detailed information about process data structure, diagnostic information, parameter addresses and the necessary information about the required IO-Link hardware and software can be found at www.ifm.com. 6.2 Teach button 6.2.1 Start programming mode.
  • Page 5 Echo LED green flashing Short circuit at the output. Reflector is outside the detection zone. > Echo LED green OFF. > With NO function = switching output active. With NC function = switching output inactive. Technical data and further information at www.ifm.com.
