WALL MOUNT

UPPER
MOUNT
BRACKET
PANEL PANEL
CUTOUT CUTOUT
LOWER
MOUNT
BRACKET
STUD OR STUD OR
STUD MT SCREWS 4 REQD. STUD MT SCREWS 4 REQD.
FRAME FRAME
(SUPPLIED BY OTHERS) (SUPPLIED BY OTHERS)
CEILING CEILING
UPPER
BRACKET
CONTROL CONTROL
BOARD BOARD
Fig. 2 Fig. 2
POWER SUPPLY POWER SUPPLY
(2) TRANSFORMERS (2) TRANSFORMERS
(OPTION 277V) (OPTION 277V)
LOWER
BRACKET
16" CRS 16" CRS
CONTROL BOARD CONTROL BOARD
A A
LAMP LAMP
LAMP LAMP
B B
1 1
2 2
POWER SUPPLY POWER SUPPLY
10"
3 3/8" 3 3/8"
11 3/4"
B B
15 1/2" 15 1/2"
Backbox Installation Backbox Installation
TOP OR SIDE LINE TOP OR SIDE LINE
POWER 120 VAC POWER 120 VAC
GENERATOR GENERATOR
FEED 120 VAC FEED 120 VAC
15 1/2" 15 1/2"
STUD OR STUD OR
FRAME FRAME
Fig. 1 Fig. 1
LAMP HOUSING LAMP HOUSING
BACKBOX BACKBOX
LENGTH LENGTH
15 1/2" 15 1/2"
-3- -3-
Series CVRAC Series CVRAC
1. Backbox mounts to stud on either left or
right side. Select side to mount and attach
upper and lower mount brackets with (4)
#6-32 sheet metal screws provided.
2. See Table 1 below. Determine panel
cutout location desired. Place backbox into
position with face flush or just below stud
face. Mark mount bracket hole locations.
NOTE: Upper bracket holes should be a
minimum of 3" from upper joist or ceiling
panel.
3. Drill pilot holes in stud at marked
locations, and mount backbox in position
with (4) mount screws installed firmly.
Both upper and lower mount brackets
must be used. Fixture weight may be up
to 15 lbs.
Table 1 Table 1
PANEL CUTOUT PANEL CUTOUT
A A
9" 9"
B B
6" 6"
