Operating instructions
ON-OFF
Press the [On/Off] button to turn the thermostat ON or OFF.
Set point
Press the [+] or [-] buttons once to view the set point temperature.
Press again to adjust the set point.
Modes
Press the [Mode] button to switch between modes:
"Cool"..................... Cooling
"Heat"..................... Heating
"Cool" & "Heat"......... Auto mode
"Fan"...................... Fan only
Notes:
- During demand for cooling or heating, the active mode will flash.
Fan speeds (in 3 speed configuration)
Press the [Fan] button to switch between fan speeds:
"Lo"........................ Low speed
"Me"........................Medium speed
"Hi".........................Hi speed
"Lo", "Me" & "Hi"........ Auto speed
Note: the actual speed indication will flash,
When the fan is active.
Auto fan (fan on demand)
Press and hold the [Fan] button to turn Auto fan ON or OFF.
When ON, the fan will work on demand for cooling or heating,
When OFF, the fan will work continuously.
Notes:
1. Auto fan cannot be selected in Fan only mode.
2. In oil heater configuration, When auto fan is selected, the fan will turn OFF.
ETN24-PMH-SUPER
Owner's manual & Technnician Settings
o
Cool
Pg. 1
Tel: +972-3-9626462
Fax: +972-3-9626620
support@meitavtec.com
Cool
Heat
Heat
Cool
Heat
Me
Lo
Low
Medium
File: etn24-pmh-super_operating manual.vsd
Fan
Auto
Fan only
mode
Hi
Hi
Me
Lo
Hi
Auto
speed
Auto Fan
Auto fan
Auto fan
OFF
ON
Advertisement
Related Manuals for meitav-tec ETN24-PMH-SUPER
Summary of Contents for meitav-tec ETN24-PMH-SUPER
- Page 1 1. Auto fan cannot be selected in Fan only mode. Auto fan Auto fan 2. In oil heater configuration, When auto fan is selected, the fan will turn OFF. File: etn24-pmh-super_operating manual.vsd Pg. 1 Tel: +972-3-9626462 ETN24-PMH-SUPER Fax: +972-3-9626620 Owner’s manual & Technnician Settings support@meitavtec.com...
-
Page 2: Installation
Installation The ETN24-PMH-SUPER is designed for wall mounting in the room to be controlled. It should be located where the occupant can easily read the LCD display and use the controls. If the built in temperature sensor is being used to measure room temperature, the module should be placed where the temperature is representative of the general room conditions. -
Page 3: Dip Switch Settings
1 2 3 4 5 6 Electric Note: In oil heater configuration, When auto fan is selected, the fan will turn OFF. heater 1 2 3 4 5 6 Oil heater Pg. 3 Tel: +972-3-9626462 ETN24-PMH-SUPER Fax: +972-3-9626620 Owner’s manual & Technnician Settings support@meitavtec.com... -
Page 4: Temperature Scale
- Unit will return to previous state after an electrical blackout (On/Off) Start/Stop On/Off (remains off) (return to Press the [Mode] button again to return to normal display. previous state) Pg. 4 Tel: +972-3-9626462 ETN24-PMH-SUPER Fax: +972-3-9626620 Owner’s manual & Technnician Settings support@meitavtec.com... - Page 5 - Return the batteries cover to place. to normal display. Important: The remote control will not operate unless at least 10 minutes pass between removing the old batteries and installing the new ones. Pg. 5 Tel: +972-3-9626462 ETN24-PMH-SUPER Fax: +972-3-9626620 Owner’s manual & Technnician Settings support@meitavtec.com...
