- Page 1 V-ZUG Ltd Range hood DI-SMC12 Operating instructions...
- Page 2 The model number corresponds to the first three digits on the identification plate. These operating instructions apply to the model: Type Model no. DI-SMC12 Variations depending on the model are noted in the text. © V-ZUG Ltd, CH-6301 Zug, 2009...
-
Page 3: Table Of Contents
Contents Safety precautions Before using for the first time ......Correct use ........Children in the home . -
Page 4: Safety Precautions
Safety precautions The appliance corresponds to recognised technology standards and the relevant safety regulations. Proper use of the appliance is however essential to avoid damage and accidents. Please there- fore follow the precautions given in these operating instructions. In accordance with the requirements of IEC 60335-1: This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless supervised or unless they have been given instruction... -
Page 5: Correct Use
… Safety precautions Correct use The appliance should only be used together with a suitable comfort venti- lation system from Zehnder Comfosystems. Other comfort ventilation appli- ances or external blowers are not equipped with the necessary safety features. Please follow the operating instructions and safety precautions recommended by Zehnder Comfosystems. -
Page 6: Note On Use
… Safety precautions Note on use If the appliance is visibly damaged, do not use it. Contact our Customer Services. If the appliance is not operating properly, disconnect it from the electricity supply immediately. Caution: Accessible parts may become hot when used with cooking appliances. - Page 7 … Safety precautions With the simultaneous operation of firing (e.g. wood, gas, oil or coal-fired heating systems), safe operation is only possible providing a room nega- tive pressure of 4 Pa (0.04 mbar) is not exceeded at the location of the ap- pliance.
-
Page 8: Appliance Description
Appliance description The appliance is designed for use in the home for extracting cooking vapours from above the cooking area. The combi filters and metal grease filters clean the extracted air. The grease particles in the cooking vapour are trapped very efficiently in the combi filters and metal grease filters. -
Page 9: Construction
… Appliance description Construction Illumination on/off Halogen spot Combi filter Metal grease filter Temperature sensor The temperature sensor 5 is only visible when the filter has been removed. -
Page 10: Use
Operation The appliance is operated via the comfort ventilation control system. Please observe the operating instructions for the comfort ventilation system. Illumination Press the button to switch the illumination for on/off. Depending on the model and features, the specification can differ from the standard specification described. -
Page 11: Care And Maintenance
Care and maintenance Cleaning the housing Take care that no water gets into the housing of the appliance! If water gets into the housing, it can cause damage. Do not use abrasive cleaners, scouring pads, steel wool etc. to clean the appliance as they can damage the surface. -
Page 12: Cleaning The Grease Filters
… Care and maintenance Cleaning the grease filters The grease filters should be cleaned at least once a month with normal use. If properly cared for, the grease filters should provide unlimited years of service. The grease filters can be cleaned in a dishwasher. Select an «intensive»... -
Page 13: Cleaning The Temperature Sensor
… Care and maintenance Cleaning the temperature sensor The temperature sensor is only visible when the filter has been removed. Clean the temperature sensor carefully with a soft cloth and a little detergent. Removing the metal grease filters and the combi filters Loosen the fastening screw 1 in one combi filter. -
Page 14: Changing The Halogen Spot
… Care and maintenance Installing the metal grease filters and the combi filters Replace the metal grease filters. Push one combi filter into the fitting and fold upwards. Tighten the fastening screw 1 slightly. Install the other combi filters in the same way. Changing the halogen spot Remove screw fuse or switch off circuit breaker. -
Page 15: Trouble-Shooting
Trouble-shooting What to do if … … the illumination is not working Possible cause Solution Fuse or circuit breaker for Change the fuse. electrical installations in Reset the circuit breaker. the home is faulty. Interruption in the power Check the power supply. supply. -
Page 16: Accessories And Spare Parts
Accessories and spare parts Please give model number and exact description when ordering parts. Halogen spot (12 V / 20 W) Metal grease filter Left Combi filter Right The halogen spot is also available from specialized retailers. -
Page 17: Technical Data
Technical data Electrical connection See identification plate Remove metal grease filter. – The identification plate is located on the inside of the appliance. -
Page 18: Disposal
Disposal Packaging All packaging materials (cardboard, plastic film (PE) and polystyrene (EPS)) are marked and should, if possible, be collected for recycling and disposed of in an environmentally friendly way. Disconnection Disconnect the appliance from the mains. With a fixed appliance, this is to be carried out by a qualified electrician! Safety Disable the appliance to prevent accidents caused by improper use,... -
Page 19: Notes
Notes... - Page 20 … Notes...
- Page 21 … Notes...
-
Page 22: Index
Index Accessories ........16 Maintenance......... 11 Appliance description ....8 Metal grease filter ......9 Model no.......... 2 Care..........11 Children in the home ....5 Operation ........10 Cleaning ........11 Grease filters......12 Combi filter........9 Packaging........18 Construction ........ -
Page 23: Repair Service
Repair service The 'Trouble-shooting' section will help you to carry out small repairs yourself, saving you the time and trouble of calling out a service engineer and the cost that goes along with it. Whether you contact us about a malfunction or an order, please always state the serial number (FN) and the model type of your appliance. - Page 24 V-ZUG Ltd Industriestrasse 66, CH-6301 Zug vzug@vzug.ch, www.vzug.com J016.352-1...
