Astria Fireplaces Astria Devonshire36TEN Installation And Operation Instruction Manual

Direct-vent gas fireplace

Advertisement

Quick Links

P/N 126730-01 Rev B 01/2015
P126730-01
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
A barrier designed to reduce the risk of burns
from the hot viewing glass is provided with
this appliance and shall be installed for
the protection of children and other at-risk
individuals.
This appliance may be installed in an aftermarket permanently located, manufactured home (USA only) or mobile
home, where not prohibited by local codes. This appliance is only for use with the type of gas indicated on the
rating plate. This appliance is not convertible for use with other gases, unless a certified kit is used.
f i r e - p a r t s . c o m
Cet appareil peut installé dans une maison préfabriquée (mobile) déjà installée à demeure, si les réglements
locaux le permettent. Ce appareil doit être utilisé uniquement avec le type de gaz indiqué sure la plaque
signalétique. Cet appareil ne peut être converti à d'autres gaz, sauf si une trousse de conversion est utilsée.
WARNING:
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings exactly could
result in serious injury, death, or property
damage.
— Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
other appliance.
— WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use
any phone in your building.
• Leave the building immediately.
• Immediately call your gas supplier from a
neighbor's phone. Follow the gas supplier's
instructions.
• If you cannot reach your gas supplier, call the
fire department.
— Installation and service must be performed by
a qualified installer, service agency or the gas
supplier.
PFS
®
C
US
Report No. F09 -099
Installateur : Laissez cette notice avec l'appareil.
Consommateur : Conservez cette notice pour consultation ultérieure.
L'écran pare-étincelles fourni avec ce foyer réduit le
risque de brûlure en cas de contact accidentel avec la
vitre chaude et doit être installé pour la protection Des
enfants et Des personnes à risques.
RISQUED'INDENDIE OU D'EXPLOSION
Le non-respect Des avertissements de sécurité pourrait
d'entraîner des blessures graves, la mort ou des dom-
mages matériels.
— Ne pas entreposer ni utilizer d'essence ni d'autres
vapeurs ou liquides inflammables dans le voisinage de
cet appareil ou de tout autre appareil.
— QUE FAIRE SI VOUS SENTEZ UNE ODEUR DE GAZ:
• Ne pas tenter d'allumer d'appareil.
• Ne touchez à aucan interrupteur. Ne pas vous servir des
téléphones se trouvant dans le bâtiment où vous trouvez.
• Sortez immédiatement de bâtiment.
• Appelez immédiatement votre fournisseur de gaz depuis
un voisin. Suivez les instructions du fournisseur.
• Si vous ne pouvez rejoindre le fournisseur de gaz, appelez
le service des incindies.
— L'installation et l'entretien doivent être assurés par un
installateur ou un service d'entretien qualifié ou par le
fournisseur de gaz.
For more information, visit Astria.US.com
Installation and Operation Instructions
Astria™ Direct-Vent Gas Fireplace
Models
Devonshire36TEN
Devonshire42TEN
AVERTISSEMENT
Devonshire36TEP
Devonshire42TEP

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Astria Devonshire36TEN and is the answer not in the manual?

Questions and answers

Summary of Contents for Astria Fireplaces Astria Devonshire36TEN

  • Page 1 Installation and Operation Instructions Astria™ Direct-Vent Gas Fireplace ® Models P/N 126730-01 Rev B 01/2015 Devonshire36TEN Devonshire36TEP Report No. F09 -099 Devonshire42TEN Devonshire42TEP P126730-01 INSTALLER: Leave this manual with the appliance. Installateur : Laissez cette notice avec l’appareil. CONSUMER: Retain this manual for future reference. Consommateur : Conservez cette notice pour consultation ultérieure.
  • Page 2 DANGER HOT GLASS WILL CAUSE BURNS. DO NOT TOUCH GLASS UNTIL COOLED. NEVER ALLOW CHILDREN TO TOUCH GLASS. A barrier designed to reduce the risk of burns from the hot viewing glass is provided with this appliance and shall be installed for the protection of children and other at-risk individuals.
  • Page 3: Table Of Contents

    Thank you for your purchase. We appreciate your TABLE OF CONTENTS business! Safety .................... 3 Please carefully read and follow all instructions in this manual. Pay Local Codes .................. 5 special attention to all warnings and safety information. Product Identification ..............5 Following these safety, care, and operation instructions will help Product Features ................
  • Page 4 SAFETY Continued Carbon Monoxide Poisoning: Early signs of carbon monoxide poison- Installation and repair should be done by a qualified ing resemble the flu, with headaches, dizziness or nausea. If you have service person. The appliance should be inspected these signs, the fireplace may not be working properly. Get fresh air before use and at least annually by a professional at once! Have fireplace serviced.
  • Page 5: Local Codes

    SAFETY Continued LOCAL CODES 6. Have venting system inspected annually by a qualified service Install and use fireplace with care. Follow all local codes. In the ab- person. If needed, have venting system cleaned or repaired. See sence to local codes, use the current National Fuel Gas Code ANSI Cleaning and Maintenance, page 24.
  • Page 6: Requirements For The Commonwealth Of Massachusetts

    REQUIREMENTS FOR THE COMMONWEALTH OF MASSACHUSETTS COMMONWEALTH OF MASSACHUSETTS REQUIREMENTS Massachusetts Horizontal Vent Requirements These appliances are approved for installation in the US state of In the Commonwealth of Massachusetts, horizontal terminations Massachusetts if the following additional requirements are met: installed less than seven (7) feet above the finished grade must comply with the following additional requirements: •...
  • Page 7: Pre-Installation

    PRE-INSTALLATION Continued (36") " " (42") Requires IHP 5” I.D. 8” O.D. Direct Vent Pipe (36") " " (42") (36") " (36") " " (42") 24" (42") (36") " 48" (42") (36") " (36") " " (42") 44" (42") f i r e - p a r t s . c o m (36") "...
  • Page 8 PRE-INSTALLATION Continued CLEARANCES Minimum clearances to combustibles for the fireplace are as follows: *Back and sides 1" Perpendicular walls 6" Floor 0" Ceiling to louver opening 42" (36") " Front 36" 48" (42") Top of Standoffs 0" Vent (See venting instructions for specific venting clearances.) (36") "...
  • Page 9: Location Of Termination Cap

    LOCATION OF TERMINATION CAP Fixed Openable Fixed Closed Closed Openable TERMINATION CAP AIR SUPPLY INLET GAS METER RESTRICTED AREA (TERMINATION PROHIBITED) A = clearance above grade, veranda, porch, deck, or I = clearance to service regulator vent outlet [*72" (182.9 cm) balcony [*12"...
  • Page 10: Venting Installation

    VENTING INSTALLATION NOTICE: Read these instructions completely before WARNING: This gas fireplace and vent assembly attempting installation. must be vented directly to the outside. The venting system must NEVER be attached to a chimney serving These models are tested and approved for use with an IHP (direct a separate solid fuel burning appliance.
  • Page 11 VENTING INSTALLATION Continued 5. Noncombustible Exterior Wall: Position horizontal vent cap in center of the 8 " round hole and attach to exterior wall with four wood screws Female provided. Before attaching vent cap to exterior wall, run a bead of non- Locking Lugs hardening mastic (pliable sealant) around outside edges to make a seal between it and outside wall.
  • Page 12 VENTING INSTALLATION Continued Horizontal Termination Configurations Cut Siding Away to Figure 15 shows a configuration for venting with horizontal termi- Fit Standoff nation with a chart of critical minimum and maximum dimensions which MUST be met. Standoff Wood Figure 16, page 13, shows a configuration for venting with horizontal Screw termination using two 90°...
  • Page 13 VENTING INSTALLATION Continued Flat Ceiling Installation 1. Cut an 11 " square hole in ceiling using locating hole as a center point. Opening should be framed to 11 " x 11 " inside dimen- sions, as shown in Figure 10 on page 11 using framing lumber the same size as ceiling joists.
  • Page 14 VENTING INSTALLATION Continued Note: If vent pipe passes through any occupied areas above first floor, including storage spaces and closets, you must enclose pipe. You may frame and sheetrock enclosure with standard construction material. Make sure and meet the minimum allowable clearances to combustibles. Do not fill any required air spaces with insulation.
  • Page 15: Fireplace Installation

    FIREPLACE INSTALLATION CHECK GAS TYPE IMPORTANT: Install main gas valve (equipment shutoff valve) in an accessible location. The main gas valve is for turning on or shutting Use proper gas type for the fireplace unit you are installing. If you off the gas to the appliance.
  • Page 16 FIREPLACE INSTALLATION Continued CONNECTING FIREPLACE TO GAS SUPPLY WARNING: Use pipe joint sealant that is resistant Installation Items Needed to liquid petroleum (LP) gas. • 5/16" hex socket wrench or nut-driver We recommend that you install a sediment trap/drip leg in supply line •...
  • Page 17 FIREPLACE INSTALLATION Continued REMOVING/REPLACING GLASS DOOR Equipment Shutoff Valve CAUTION: Do not operate this fireplace with a bro- Propane/LP ken glass door panel or without the glass door panel Supply Tank securely in place. For replacement part information see Replacement Parts, page 34. CAUTION: Wear gloves and safety glasses while handling or removing broken glass.
  • Page 18 FIREPLACE INSTALLATION Continued Replacing Glass Door 3. Place lava rock around base of burner. Make sure burner ports are not covered (see Figure 30, page 19). 1. Position door frame in front of firebox opening with bottom of 4. Place ember flakes around front and sides of burner and on burner door tilted away from firebox (see Figure 27).
  • Page 19 FIREPLACE INSTALLATION Continued Equipment Lava Rock To Gas Supply Shutoff Valve (Natural) Millivolt Control Valve To External Regulator (Propane/LP) Flexible Gas Line, Do NOT Kink Figure 30 - Installing Lava Rock Figure 33 - Connecting/Disconnecting Gas Line to Millivolt Valve WARNING: Never use an open flame to check for a leak.
  • Page 20: Operation

    FIREPLACE INSTALLATION Continued REPLACING BATTERIES IN HAND-HELD REMOTE CONTROL AND 6. Insert battery pack back into metal housing. AC BATTERY BACKUP 7. Replace bottom access door. Replacing Batteries in AC Battery Backup Installing Batteries in Remote Control Unit 1. Remove bottom access door. 1.
  • Page 21 OPERATION Continued BLOWER CONNECTION AND OPERATION Note: The blower assembly, is for application into direct-vent models listed on the front page of this manual only and is already factory installed. When operating the blower, you must first check that all wiring connections are secure from the speed control to the blower (See Figure 36). White Wires Exhaust Port Ring Connectors...
  • Page 22: Gas Control Module System

    GAS CONTROL MODULE SYSTEM The module has 2 special features built into the system. Learn Button AUX Connection CONTINUOUS PILOT FEATURE This allows the change from a spark to pilot system to a standing pilot system. There is a switch located on the right side of the module that reads CONTINUOUS PILOT ON/OFF.
  • Page 23: Inspecting Burners

    INSPECTING BURNERS Check pilot flame pattern and burner flame patterns often. BURNER FLAME PATTERN Burner flames will be steady, not lifting or floating. Flame patterns will PILOT ASSEMBLY be different from unit to unit and will vary depending on installation The pilot assembly is factory preset for the proper flame.
  • Page 24: Cleaning And Maintenance

    CLEANING AND MAINTENANCE WARNING: Turn off fireplace and let cool before CAUTION: Do not vacuum if pieces are hot. cleaning. Use only glass door replacement intended for this fireplace (see Replacement Parts, page 34 for detail on ordering). No substitutions CAUTION: You must keep control areas, burners may be made.
  • Page 25: Troubleshooting

    TROUBLESHOOTING WARNING: Turn off fireplace and let cool before servicing. Only a qualified service person should service and repair fireplace. CAUTION: Never use a wire, needle or similar object to clean pilot. This can damage pilot unit. Note: All troubleshooting items are listed in order of operation. OBSERVED PROBLEM POSSIBLE CAUSE REMEDY...
  • Page 26 TROUBLESHOOTING Continued WARNING: If you smell gas • Shut off gas supply. • Do not try to light any appliance. • Do not touch any electrical switch; do not use any phone in your building. • Immediately call your gas supplier from a neighbor’s phone. Follow the gas supplier’s instructions. •...
  • Page 27: Specifications

    SPECIFICATIONS DEVONSHIRE36TEN DEVONSHIRE36TEP • Rating: 46,000/30,000 Btu/hr • Rating: 41,000/25,000 Btu/hr • Gas Type: Natural Gas Only • Gas Type: Propane/LP Gas Only • Ignition: Electronic • Ignition: Electronic • Manifold Pressure: 3.5" w.c. • Manifold Pressure: 10" w.c. • Minimum Inlet Supply Pressure: 5" w.c. •...
  • Page 28: Parts

    PARTS WARNING: Contact an IHP dealer to obtain any of these parts. Never use substitute materials not approved by IHP. Use of non-approved parts can result in poor performance and safety hazards. BURNER ASSEMBLY MODELS: DEVONSHIRE36TEN (F1544 / F1545 / F1546 / F1547 / F1548) DEVONSHIRE36TEP (F1549 / F1550 / F1551 / F1552 / F1553) DEVONSHIRE42TEN (F1557 / F1558 / F1556 / F1554 / F1555) DEVONSHIRE42TEP (F1559 / F1563 / F1561 / F1562 / F1560)
  • Page 29 PARTS This list contains replaceable parts used in your fireplace. When ordering parts, follow the instructions listed under Replacement Parts on page 34 of this manual. NO. CATALOG NO. PART NO. DESCRIPTION Devonshire36TEN Devonshire36TEP Devonshire42TEN Devonshire42TEP QTY. J7676 125105-01 Door Assembly, 36" •...
  • Page 30 PARTS BURNER ASSEMBLY MODELS: DEVONSHIRE36TEN (F1544 / F1545 / F1546 / F1547 / F1548) DEVONSHIRE36TEP (F1549 / F1550 / F1551 / F1552 / F1553) DEVONSHIRE42TEN (F1557 / F1558 / F1556 / F1554 / F1555) DEVONSHIRE42TEP (F1559 / F1563 / F1561 / F1562 / F1560) f i r e - p a r t s .
  • Page 31 PARTS BURNER ASSEMBLY This list contains replaceable parts used in your fireplace. When ordering parts, follow the instructions listed under Replacement Parts on page 34 of this manual. This table uses catalog numbers for clarity on models. WARNING: Contact an IHP dealer to obtain any of these parts. Never use substitute materials not approved by IHP.
  • Page 32 PARTS REFRACTORY PARTS This list contains replaceable parts used in your fireplace. When ordering parts, follow the instructions listed under Replacement Parts on page 34 of this manual. This table uses catalog numbers for clarity on particular models. WARNING: Contact an IHP dealer to obtain any of these parts. Never use substitute materials not approved by IHP.
  • Page 33 PARTS This list contains replaceable parts used in your fireplace. When ordering parts, follow the instructions listed under Replacement Parts on page 34 of this manual. This table uses catalog numbers for clarity on particular models. WARNING: Contact an IHP dealer to obtain any of these parts. Never use substitute materials not approved by IHP.
  • Page 34: Replacement Parts

    REPLACEMENT PARTS ACCESSORIES Note: Use only original replacement parts. This will protect your Purchase these accessories from your local dealer. If they can not sup- warranty coverage for parts replaced under warranty. ply these accessories call IHP at 1-800-655-2008 for information. You can also write to the address listed on the back page of this manual.
  • Page 35: Warranty

    Innovative Hearth Products Astria™ Brand Gas Fireplace Limited Lifetime Warranty THE WARRANTY Innovative Hearth Products ("IHP") Limited Lifetime Warranty warrants your Astria™ brand gas fireplace ("Product") to be free from defects in materials and workmanship at the time of manufacture. The Product body and firebox carry the Limited Lifetime Warranty. Ceramic glass carries the Limited Lifetime Warranty against thermal breakage only.
  • Page 36 WARRANTY KEEP THIS WARRANTY Model (located on product or id tag) Burner System _________ Cast Stove ___________ Serial No. (located on product or identification tag) ___________________ Date Purchased ______________________ Keep receipt for warranty verification. f i r e - p a r t s . c o m Innovative Hearth Products reserves the right to make changes at any time, without notice, in design, materials, specifications, prices and also to discontinue colors, styles and products.
