Led Diagnostics; Terminal Identification - Altronix LPS3WP12 Installation Manual

Red (DC) Green (AC)
ON ON
ON OFF
OFF ON
OFF OFF
Terminal Legend
AC AC
BAT +
–
DC +
–
The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user
to the presence of an insulated DANGEROUS VOLTAGE within the product's enclosure that may
be of sufficient magnitude to constitute an electric shock .
The exclamation point within an equilateral triangle is intended to alert the user to the presence of
important operating and maintenance (servicing) instructions in the literature accompanying
the appliance .
- 6 -

LED Diagnostics:

Power Supply Status
Normal operating condition .
Loss of AC . Stand-by battery is supplying power .
No DC output .
Loss of AC . Discharged or no stand-by battery . No DC output .

Terminal Identification:

Function/Description
Low voltage AC input:
LPS3WP12 - 16 .5VAC/56VA
LPS3WP24 - 28VAC/100VA .
Stand-by battery connections .
LPS3WP12 - 12VDC @ 2 .5A continuous output .
LPS3WP24 - 24VDC @ 2 .5A continuous output .
CAUTION: To reduce the risk of electric shock do not open
enclosure . There are no user serviceable parts inside .
Refer servicing to qualified service personnel .
LPS3WP Series
