Prevue Hendryx F040 Quick Start Manual

Flight Cage
Model: # F040 [A]
1
To assemble the BASE,
you will need these pieces:
2
To assemble the SIDES,
you will need these pieces:
×
F040 [A] — 03 / 15 — USL
read first
• TOOLS: Allen wrench (included). Needle nose
pliers (not included) will be useful. If power
tools are used, Prevue is not responsible
for damage caused by misuse.
• Two-person assembly for best results.
×4
×4
Attach the storage shelf to the leg
frames to create the base. Back
ends of leg frames have a backstop
tab at the track ends (fig.1-1).
Stack the side panels in place
on the base. For correct assembly,
note these details:
• top side panel: has a finished
corner (fig. 2-1).
• bottom side panel: top horizontal
surface has small holes near the
center and open-frame corners
(fig 2-2), to align with posts and
wires from the top side panel
(fig 2-3).
• nest doors swing out
Notes: Have an assistant holding
side panels for best results.
Straighten extended wires or remove
hole slugs with needle nose pliers.
Made in China for Prevue Pet Products, Inc., Chicago IL USA
REVIEW BEFORE ASSEMBLY
For assistance or replacement parts,
please contact Prevue Pet Products:
TOLL-FREE 800.243.3624
ONLINE
EMAIL
[ FIG. 1-1]
Flip assembled unit over
and fully insert casters into
frame legs.
www.prevuepet.com 800 243-3624
www.prevuepet.com
customerservice @ prevuepet.com
[ FIG. 2-1]
[ FIG. 2-2 ]
[ FIG. 2-3 ]
