Features
• 4 preprogrammed steeping timers for green, white,
black and herbal teas
• 1 programmable up/down all-purpose timer
• All 5 channels count separately or simultaneously
• Big digit
• Loud alarm
• Long alarm
• Unique alarm sounds for each channel
• Stop & restart
• Last count recall in 4 channels
• ABS plastic
• On/off switch
• Temperature guide on timer
• 4-way mounting: pocket clip/magnet/stand/hang
Note: Remove sticker from display before use.
Note: In the following instructions, names of the control
buttons are shown in CAPS. Function information that appears
on the display is shown in BOLD CAPS.
Battery Installation
Battery is installed. Remove plastic tab to allow power.
Replace battery when LCD becomes dim or alarm level
declines.
1. Slide the POWER switch on the back to the OFF
position.
2. Remove battery cover on the back by sliding it in the
direction of the arrows.
3. Install one 1.5V AAA battery observing polarity shown
in compartment.
4. Replace the battery cover until it clicks shut.
5. Slide the POWER switch on the back to the ON
position. A brief alarm sounds and the display flashes
all segments.
Operating Instructions
A. On/Off
Slide the POWER switch on the back to turn it on
or off.
B. Tea Timers
1. When the water is at the appropriate temperature
listed on the back of the timer, press the button for
the tea being steeped. GREEN, WHITE, OOLONG/
BLACK and/or HERBAL appear on the display
above the respective length of time.
2. Press the START/STOP button to start counting
down.
Note: The channel name flashes on the display during
count down when in other channels.
3. Press the START/STOP button to interrupt
the count. Press START/STOP again to resume
the count.
4. The alarm sounds and the alarm icon () flashes on
the display when the count reaches 0:0000.
Note: Each channel has a unique alarm sound.
5. Press any button to stop the alarm and flashing.
The last count is recalled.
Note: The alarm and flashing stop automatically after 60
seconds.
Model: TMT1
Tea Timer
100 hours by hr/min/sec
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for CDN TMT1
Summary of Contents for CDN TMT1
- Page 1 Model: TMT1 Tea Timer 100 hours by hr/min/sec Features Note: In the following instructions, names of the control buttons are shown in CAPS. Function information that appears on the display is shown in BOLD CAPS. • 4 preprogrammed steeping timers for green, white, black and herbal teas Battery Installation • 1 programmable up/down all-purpose timer • All 5 channels count separately or simultaneously Battery is installed. Remove plastic tab to allow power. • Big digit Replace battery when LCD becomes dim or alarm level • Loud alarm declines. • Long alarm 1. Slide the POWER switch on the back to the OFF position. • Unique alarm sounds for each channel • Stop & restart 2. Remove battery cover on the back by sliding it in the direction of the arrows. • Last count recall in 4 channels • ABS plastic 3. Install one 1.5V AAA battery observing polarity shown in compartment. • On/off switch • Temperature guide on timer 4. Replace the battery cover until it clicks shut. • 4-way mounting: pocket clip/magnet/stand/hang 5. Slide the POWER switch on the back to the ON...
- Page 2 3. Count Up or obligation. a. When timer is stopped, press both HOUR and MIN buttons simultaneously to reset to 0:0000. b. Press the START/STOP button to begin the 5-Year Limited Warranty: Any instrument that proves to be defective in material or workmanship count up. within five years of original purchase will be repaired Note: The channel name flashes on the display during or replaced without charge upon receipt of the count up when in other channels. unit prepaid at: CDN, PO Box 10947, Portland, OR c. Press the START/STOP button to interrupt the count. 97296-0947. This warranty does not cover damage Press START/STOP again to resume the count. in shipment or failure caused by tampering, obvious carelessness or abuse. d. When timer is stopped, press both HOUR and MIN buttons simultaneously to reset to 0:0000. For more detailed information on our products, please visit cdn-timeandtemp.com. CE Note: This device could be sensitive to electrostatic discharge. If electrostatic discharge or malfunctioning occurs,...
