Rack Mechanical Drawing And Dimensions - Altronix R1224DC16CBV Installation Manual

Rack Mechanical Drawing and Dimensions (H x W x D approximate):
Unit with Rack Brackets Attached:
Fig. 3
3a
3.26"
83mm
8.5"
216mm
Illuminated master power disconnect circuit breaker:
OFF position - Switch not illuminated. Outputs not powered.
RESET (ON) position - Switch illuminated. Outputs powered.
Circuit breaker tripped - Switch not illuminated. Power LEDs on
faceplate are not illuminated. Outputs not powered.
To reset circuit breaker set power switch to the ON (RESET) position.
LED
1" (25.4mm)
Altronix is not responsible for any typographical errors.
140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056
web site: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty | Made in U.S.A.
IIR1224DC16CBV
- 4 -
Unit:
3.26" x 19.125" x 8.5" (83mm x 486mm x 216mm).
IEC 320Connector
115VAC 60 Hz.
4a 4b 4c 4d 3a
LED
5.21" x 19.125" x 8.5" (132.3mm x 486mm x 216mm)
3b
REAR
3b 3c 3d 2a
17.625"
447.7mm
BOTTOM
FRONT
LED LED
19.125"
486mm
J16Q
3c
2b 2c 2d 1a 1b
3d
1a 1b 1c 1d
1c 1d
5.21"
132.3mm
MEMBER
R1224DC16CBV
