Lumex 2190A Assembly & Operation Instructions

A Graham-Field Brand
Warning: Please read all instructions before use. Do not use this product without proper
instruction from a healthcare professional.
Warning: Commodes 2195A, 2215A, and 2232A have a maximum user weight limitation of
300 lbs.
Warning: Commode 2190A has a maximum user weight limitation of 400 lbs.
Warning: GF Health Products, Inc. assumes no responsibility for any damage or injury
caused by improper installation, assembly or use of this product.
Warning: If components are damaged or missing, contact your dealer immediately. DO NOT
use substitute parts.

Set-Up

1. Remove pail, cover, and
splash shield from carton.
2. In the upright position,
place splash shield or pail
and cover in frame (see
picture at right).
Insert back bar (2190A,
2195A and 2215A only)
1. Remove back bar from
carton.
2. Insert back bar into channel
guides on back of commode
until back bar push buttons
protrude fully through
channel guide holes (see
pictures at right).
2190A, 2195A, 2215A, 2232A: Three-in-One Aluminum Commode
GF0500015REVA05 ©GF Health Products, Inc., February 2005
2190A, 2195A, 2215A, 2232A:
THREE-IN-ONE ALUMINUM COMMODE
ASSEMBLY & OPERATION INSTRUCTIONS
PLEASE SAVE THESE INSTRUCTIONS FOR FUTURE USE
set-up (2232A shown)
insert back bar (2215A shown)
frame
pail
back bar
channel guide
push button
