Rp240 Remote Operator Panel; Input Power - Parker Compumotor 6200 Installation Manual

RP240 Remote Operator Panel

Input Power

AC Input — 110-240VAC (±10%) single-phase, 50/60Hz, 0.6A @ 120VAC
120VAC Input
Grounded
120VAC
Power Source
8-foot Power Cord
(part # 44-000054-01)
provided in the ship kit
Cable Lead Color Signal
Black AC Line
White AC Neutral
Green Earth Ground
1 8
6200 Installation Guide
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
RP240 Back Plane
GND
Rx
Tx
+5V
WARNING
: The 6200's SHLD terminals are grounded
through the AC power connector ground pin. You must
provide a proper AC power ground for safety purposes.
1. Remove the cover
2. Build your power
3. Slide the power
4. Connect the
5. Lock the conductor
6. Reassemble the
RP240
+5V
GND
Rx
Tx
SHLD
240VAC Input
Grounded 240VAC
Power Source
on the EIA plug.
cable as shown.
DO NOT USE THE
25mm
120VAC CABLE.
6mm
cable into the plug.
conductor wires.
wires under the
clamp.
plug.
AC Neutral
User supplied
power cable with
a cross section of
each conductor at
2
1 mm (18 AWG)
EIA plug
(part # 44-011905-01)
from the ship kit
Clamp
Ground
AC Line
