Chapter 1. Installation - Parker Compumotor 6200 Installation Manual

1
C H A P T E R O N E
Installation
• Product ship kit list
• Things to consider before you install the 6200
• General specifications table
• Optional pre-installation alterations (requires removal of chassis)
- DIP switch settings for device address and autobaud feature
- Jumper setting for programmable inputs to source or sink current
• Mounting the 6200
• Connecting all electrical components (includes specifications)
• Testing the installation
• Preparing for what to do next
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
IN THIS CHAPTER
To install the 6200 so that it is LVD compliant, refer to the supplemental instructions in
Appendix B. Appendix C provides guidelines on how to install the 6200 in a manner
most likely to minimize the 6200's emissions and to maximize the 6200's immunity to
externally generated electromagnetic interference.
