Follow all instructions and warnings for inspecting, maintaining and operating this product.
The use of any hoist presents some risk of personal injury or property damage. That risk is greatly increased if proper
instructions and warnings are not followed. Before using this hoist, each operator should become thoroughly familiar with all
warnings, instructions and recommendations in this manual. Retain this manual for future reference and use.
Forward this manual to operator. Failure to operate equipment as directed in manual may cause injury.
Electronic Control Unit SLE 3
Operation Manual
Before installing hoist, fill in the information below.
Refer to the Hoist and Motor data plates.
Model No.
Serial No.
Purchase Date _____________________________________
Voltage
Rated Load
_____________________________________
_____________________________________
_____________________________________
_____________________________________

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SLE 3 and is the answer not in the manual?

Questions and answers

Summary of Contents for Yale SLE 3

  • Page 1 Electronic Control Unit SLE 3 Operation Manual Before installing hoist, fill in the information below. Refer to the Hoist and Motor data plates. Model No. _____________________________________ Serial No. _____________________________________ Purchase Date _____________________________________ Voltage _____________________________________ Rated Load _____________________________________ Follow all instructions and warnings for inspecting, maintaining and operating this product.
  • Page 3: Table Of Contents

    Residual risks ........................................10 Product and functional description ................................11 Description ........................................11 Load sensor ........................................11 Front view ......................................... 12 Block diagram SLE 3 ....................................... 13 Schematic circuit diagram ..................................... 14 Safety functions ....................................... 14 3.6.1 Overload cut-off ......................14 3.6.2...
  • Page 4 Type designation ......................................33 09.2019...
  • Page 5: General Information

    General information on these operating instructions These operating instructions serve as safety manual in the sense of the safety stand- ards for functional safety of the SLE 3 electronic control unit for the manufacturer's hoists. They are aimed at the manufacturers, operators, commissioning engineers and service personnel of hoists.
  • Page 6: Symbols

    General information Symbols The safety instructions in the manual are subdivided according to the severity of the hazard and the likelihood of it occurring. The measures described to avoid the hazards must be followed. DANGER This symbol warns of a direct danger to the health and life of people. Disregarding these warnings will lead to severe injuries, possibly also death.
  • Page 7: Target Group

    Commissioning / Operation / Documentation WARNING The SLE 3 only achieves its safety function when it has been programmed accordingly. The commissioning of a hoist must be documented. This documentation must also contain the overload cut-off point. The signature of the qualified person and the operator is needed after commissioning (section “Commissioning and testing”).
  • Page 8: 1.10 Standards And Directives

    Machinery Directive 2006/42/EC and • EMC Directive 2014/30/EU The SLE 3 was built in accordance with the following valid European standards and regulations: • IEC / EN 60204-32 – "Safety of machinery – Electrical equipment of machines – Part 32: Requirements for hoisting machines"...
  • Page 9: General Safety Instructions

    General safety instructions General safety instructions WARNING You must follow the safety instructions: • National and international directives and regulations must be followed for assembly, commissioning, operation and period tests, in particular the Machinery Directive 2006/42/EC, safety rules and country-specific safety regulations. •...
  • Page 10: Residual Risks

    WARNING Failure of one of the downstream power elements • Downstream power elements are not monitored by the SLE 3. • Failure is to be prevented by the designer of the control equipment by suitable choice. • In the event of failure the operator must have the power element replaced immediate- ly by a competent person.
  • Page 11: Product And Functional Description

    Product and functional description Description The SLE 3 is an electronic control unit for hoists. The device can be used to control pole- changing or frequency-controlled drives. It contains a safety-related overload cut-off for hoists in conjunction with a load sensor. It is a configurable system that only performs the overload protection function after parameterisation and storage of the safety-relevant parameter (overload cut-off point) in that the lifting movement is switched off safely.
  • Page 12: Front View

    Product and functional description Front view Display board S1: Selector switch motor management Signaling and S4: Setting cut-off point, rough status LEDs S2: Setting cut-off point, fine S3: DIP switch: to activate the testing bay functions, relay operation and motor man- agement S5: Enter button: e.g.
  • Page 13: Block Diagram Sle 3

    Product and functional description Block diagram SLE 3 Legend Connection terminals Supply 1: Power supply 2: Power supply reference point Actuation 3: Safety input lift S↑ 4: Safety input lower S↓ Analogue inputs Signaling relay ϑ ϑ 5: Input fast S↕↕...
  • Page 14: Schematic Circuit Diagram

    • If the signal voltage between the connections IN+ and IN- exceeds the cut-off thresh- old setting while the outputs K↓ and K↓↓ are active or when stationary, the SLE 3 detects "overload" after a time of 800 ms and blocks the outputs K↑ and K↑↑ until no overload is detected any more.
  • Page 15: Sensor Errors

    Actuation of S↕↕ is only recognised if the corresponding direction S↑ or S↓ is active at the same time. If S↑ or S↓ is actuated from idle state, the SLE 3 switches the respective safety output K↑ or K↓ after a maximum delay time of 300 ms.
  • Page 16: Relay Outputs

    Product and functional description 3.7.2 Relay outputs The relay outputs switch the voltage connected to L↑↓ through to the downstream actuators (e.g. contactor). The control voltage at L↑↓ must correspond to the power supply at L. The safety outputs K↑ and K↑↑ are actuated by a safe internal circuit according to Category 2 Performance Level d.
  • Page 17 A-xxx Frequency- controlled Motor management parameters for motors from Yale and third-party motors – F = Setting for operation with a frequency inverter – In setting 8 … E, the highest setting, as in item 7, is retained Operation with frequency inverter When working with a frequency inverter, the switch S1 is set to "F"...
  • Page 18: Operating Time Counter

    The travel motor thermistor (PTC) is connected to input 2 (if two or more travel motors, for all). When a travel motor thermistor responds, the SLE 3 switches the relay outputs left/right off and reports this via the device LED (as warning) that the travel motor(s) can no longer be actuated.
  • Page 19: Signaling Relays

    Product and functional description 3.7.6 Signaling relays CAUTION The signalling relays “err” and "option" are used to output error messages and may not be used for safety-relevant functions. The signalling relays may only be parameterised by an electrically skilled person. Both relays can be parameterised as normally-closed or normally-open contacts: Relay Normally-open...
  • Page 20: Installation

    Installation Installation Dimensions • 100 × 110 × 75 mm (W × H × D) Attachment possibilities • Snap-on attachment on 35 mm top hat rail (EN 50022-35) • Screw attachment enclosure bottom (M4) using pull-out sliders Cable connection See section “Technical data”. Cables Install sensor cables (load sensor, temperature sensor) and power lines separately of each other.
  • Page 21: Commissioning, Tests, Settings And Maintenance

    SLE 3 and that the components and units in- volved in the safety function work perfectly in interaction with the SLE 3. The type of use / attachment of the SLE 3 and the follow-up of the plant must also be tested. Acceptance test: overload cut-off: Lifting of a test load of 110 % of the maximum lifting capacity.
  • Page 22: Change To The Cut-Off Point

    • Get a test load of 110 % of the maximum lifting capacity ready. • Get a load weighing the maximum lifting capacity ready. • Carefully take off the front panel (device cover) of the SLE 3 with the help of a screwdriver and put in a safe place.
  • Page 23: Activating The Testing Bay Function

    16. Set S1 back to the previously noted switch position, note the changes and confirm the settings by signing on the enclosure cover. 17. Restart the device. When the crane test is finished, put the front panel (device cover) back on to the SLE 3 to protect the electronic components against dust and foreign bodies. 09.2019...
  • Page 24: Crane Test

    The crane test can only be activated in stationary state and with no overload on the hook. The DIP switches S3 must correspond to the setting shown in the enclosure cover. Preparation: Carefully take off the front panel of the SLE 3 (transparent enclosure cover) with the help of a screwdriver. Activation procedure: The following steps must be carried out within a time of 12 seconds;...
  • Page 25: Documentation Of Changes To The Cut-Off Point

    There is a page with a table as shown above at the end of these operating instructions. This page can be taken out (or copied) and used to document changes to the settings of the SLE 3 in the test book. 09.2019...
  • Page 26: Device Or Sensor Replacement

    Wear parts ATTENTION The SLE 3 does not have any wear parts. If a device is defective, it must be replaced with an equivalent one. Here it must be ensured that the device has the following properties: •...
  • Page 27: Error And Warning Messages, Faults

    Internal tests are carried out when the power supply is switched on. The LEDs "pwr", "err", "I", "II", "III" light up during this test. The SLE 3 is ready for operation when only the LED "pwr" is still on. Symbols...
  • Page 28: Error State Indicators

    Error and warning messages, faults Error state indicators The SLE 3 constantly carries out internal tests and tests on the connected sensors and monitors the plausibility of external and internal switch states. If the SLE 3 detects a problem, an error or error state is set and lifting or lifting and lowering is blocked.
  • Page 29: Warning Messages

    Error and warning messages, faults Warning messages A warning detected and indicated by the device does not lead to any restrictions in the lifting movements. The warning is indicated by three LED indicators (flashing) on the front side. A warning can lead to impairment of the travel motion. Cause Correction Crane test mode is active.
  • Page 30: Decommissioning

    Decommissioning Decommissioning The operator is responsible for decommissioning of the plant and thus of the SLE 3. Electronic components and electric and electronic scrap are special waste. Country-specific environmental laws must be obeyed when disposing of the device. The local authorities will provide relevant information.
  • Page 31: Technical Data

    Technical data Technical data Supply Voltage variants AC voltage: DC voltage: 24 V 50 / 60 Hz 24 V DC 42 V 50 / 60 Hz Residual ripple: 48 V 50 / 60 Hz ±5 % 110/120 V 50 / 60 Hz 230 V 50 / 60 Hz Voltage tolerance 90 …...
  • Page 32 Mounting position Horizontal, vertical Maximum cable length Digital control signals 100 m Temperature inputs 50 m Sensor inputs (shielded) Safety parameter values per ISO 13849-1 SLE 3 Performance level 5.28 E-07 MTTFd 100 years 84 % Category Response time 850 ms...
  • Page 33: Rating Plates

    Rating plate for countries without UL and CSA approval requirement: Example: Rating plate for countries with UL and CSA approval requirement: There is currently not yet UL/CSA approval for the SLE 3. Type designation (d2) Temperature range...
  • Page 34 Annex Serial number Changes to the SLE 3 device setting – : ............ Setting Reason for change Operator's Service technician's signature signature Date _______________ Device Rev._________ Date _______________ Device Rev._________ Date _______________ Device Rev._________ Date _______________ Device Rev._________ Date _______________ Device Rev._________...
  • Page 35 Annex Notes 09.2019...
  • Page 36 USA: Ph: (800) 888.0985 • (716) 689.5400 • Fax: (716) 689.5644 • www.cmworks.com SINGAPORE: Ph: +65 6268 9228-201 • Fax: +65 6268 9618 • www.cmworks.com GERMANY: Ph: +49 7940 128-0 • Fax: +49 7940 55665 • www.stahlcranes.com...
