MOD :E-BIKE 7000
ENGLISH
Congratulations for purchasing this pedal assisted electric bicycle, carefully designed and manufactured by following the latest international
quality standards, including:
EN 14764-2005
EN 15194-2009
Please read this instruction manual carefully before use.
This manual contains important information on the safety and maintenance of the bicycle.
It is the purchaser's responsibility to read this manual before use.
In the event that the original components should have production defects within the expiration of the warranty period, the manufacturer will
replace them. The warranty duration for electric bicycles is the following:
Frames and Forks: 2 years
Electrical components: 1 year
Other components: 1 year, except for tyres, inner tubes and accessories that are subject to wear.
The company assumes no liability for indirect or special damages. This warranty applies only to the original purchaser, in the possession of a
fiscal document proving the exact purchase date.
This warranty is applicable only in the case of defective components and does not cover the effects of normal use or damage caused by
accidents, abuse, excessive loading, negligence, improper assembly, improper maintenance or adding objects that are inconsistent with the
normal use of the bicycle.
No bicycle is indestructible and no claims are accepted for damage caused by improper use, by use in competitions, acrobatics, jumps, leaps or
similar activities. Claims must be made at the retailer, where the bicycle was purchased.
This warranty has no effect on your rights by law.
The company reserves the right to change or correct any specification without notice. All information and specifications in this manual are
correct at the time of printing.
I. Terms and conditions for using this pedal assisted electric bicycle
This pedal assisted electric bicycle is designed to be used on the road or on paved surfaces where the tyres do not lose contact with the ground. It
must be maintained according to the instructions in this booklet
The maximum weight of the cyclist including the load must be less than 100 kg.
Safety:
Before starting to use the pedal assisted electric bicycle, make sure it is completely safe.
Specifically check:
- nuts, bolts, fasteners, and that all components to be fixed on are tightened and are not worn or damaged
- the steering position is comfortable
- the brakes work effectively
- the steering is free without too much play
- the tyres are not damaged and are inflated to the correct pressure
- the pedals are screwed correctly onto the crankarms
PLEASE NOTE: Your pedal assisted electric bicycle should be professionally checked every six months to ensure correct and safe
functioning. It is the user's responsibility to ensure all components are able to guarantee correct functioning. It is very important to check the
tyres monthly and control the wear line and, if the groove becomes invisible, the tyre is no longer working safely. A particularly worn tyre is very
dangerous and must be replaced. Adjust the brake pads at a 1-1.5mm distance from the rim.
FREQUENTLY CHECK THE TENSION OF THE SPOKES OF THE WHEEL DRIVE.
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the Orus 7000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Denver Orus 7000

  • Page 1 MOD :E-BIKE 7000 ENGLISH Congratulations for purchasing this pedal assisted electric bicycle, carefully designed and manufactured by following the latest international quality standards, including: EN 14764-2005 EN 15194-2009 Please read this instruction manual carefully before use. This manual contains important information on the safety and maintenance of the bicycle. It is the purchaser’s responsibility to read this manual before use.
  • Page 2 PLEASE NOTE: We inform you that the user assumes personal risk for injuries, damage or losses if the above conditions are violated, and the warranty will be automatically annulled. List of components for the pedal assisted electric bicycle Tyres & tube Controller box rims Battery...
  • Page 3 We recommend using a helmet during use Comply with the highway code Be aware of traffic conditions Frequent controls allow for better and safer use Do not exceed a100kg load on the bicycle, including the cyclist Never ride the bicycle with more than one person at a time Make sure maintenance is carried out according to the instruction manual Maintenance of the electrical components must be carried out by qualified staff.
  • Page 4 FIG 5 ON /OFF BUTTON: the display turns on and off 6Km/h BUTTON: By pressing this button for more than 2 seconds, the bicycle motor starts without pedalling, keeping the button pressed. The maximum the bicycle can reach is 6Km/h. As soon as the button is released, the electric aid ceases. BUTTONS+/-: by pressing these buttons, you can set the required aid for the bicycle 6 –...
  • Page 5 8 – Hub motor use and maintenance - Our electric bicycle is programmed to start the pedal assistance after one complete revolution of pedalling - Do not use the electric bicycle during a flood or storm. Do not immerse electrical parts in water as they could get damaged - Avoid any type of impact with the hub motor, otherwise, the cover and aluminium body may break - Frequently check the screws of the hub motor on both sides;...
  • Page 6 CAUTION ALL ELECTRIC CABLES HAVE AN ARROW ON THE CONNECTOR TO BE CONNECTED AND UNCONNECTED, SEE FIG 7. THE TWO ARROWS MUCH MATCH TO BE CONNECTED Fig 7 12 – Main technical specification sheet Modello Ref. E BIKE 7000 26” Here is some of the general technical data for this eletctric bikes: 25.9.V: 25~30km (total loading ≦75kgs) maximun speed with electric assistance...
