Summary of Contents for Hafele DT 750
- Page 1 DT 750 DT 750 BLE Installation and maintenance instructions - English ..2...
-
Page 2: Table Of Contents
Table of contents Notes on these instructions ..............3 1.1 Contents and target group of these instructions ........3 1.2 Obligations of the installer ..............3 1.3 Obligations of the operator ..............3 1.4 Exclusion of liability ................3 Security ....................3 2.1 Safety notes and symbols in these instructions ........ -
Page 3: Notes On These Instructions
Installation and maintenance instructions - English 1. Notes on these instructions 1.1 Contents and target It is essential to pay attention to these installation and maintenance instructions group of these in order to install the product successfully and safely. Please pay attention to all instructions of the specified installation steps, instructions and notes! These installation and maintenance instructions are intended for:... - Page 4 CAUTION This combination of symbol and signal word indicates a potentially dangerous situation that may cause minor or light injury if not avoided. NOTE The note is used to point out dangerous situations which could lead to potential property damage/consequential damage to the product or damage to the environment.
-
Page 5: Correct Purpose Of Use
2.2 Correct purpose Correct purpose of use of use The product is a battery operated electronic door fitting for use in hotels, hospitals and other buildings with frequent changes of room occupant. The operator must equip the relevant doors with a single profile cylinder for emergency opening in the event of faults or emergencies. -
Page 6: Personnel Requirements
Here, in particular: • The operator must ensure that escape routes and emergency exit doors are accessible for all people in case of danger. • The operator must be aware of the applicable occupational safety regulations and determine other hazards in a hazard assessment that may arise from the special working conditions at the place of use of the access control system. -
Page 7: Environmental Protection
Essential requirements Only those persons are authorized as personnel who can be expected to carry out their work reliably. Persons whose ability to react is affected by, e.g., drugs, alcohol, or medication are not permitted to operate the system. In the selection of personnel, observe appropriate training as well as the applicable occupation-specific regulations. -
Page 8: Safety Notes And Dangers
3. Safety notes and dangers The product has been built in accordance with the latest state of technology and the recognised technical safety regulations. Nevertheless, danger to persons or damage to product or other property could occur during installation and use. WARNING Risk of fatality due to lack of emergency opening facility If the product is installed without an emergency opening facility, it may not be... -
Page 9: Installation Conditions
NOTE The product can be damaged by condensed water on cold components > Before installation, please ensure that all product components are at the ambient temperature. > Store products at the installation site for an appropriate period prior to installation. 4.2 Installation Door leaf conditions... -
Page 10: Check Scope Of Delivery
5. Check scope of delivery WARNING Risk of suffocation from small parts and packing materials Screws, small parts and packaging materials can be be deadly playthings for children. > Do not leave the packing materials and the contents lying around carelessly, and keep away from children and babies. -
Page 11: Maintenance Instructions
NOTE Malfunction due to outdated Dialock firmware. To ensure that the current Dialock firmware is running on the terminal, the device has to be flashed (programmed) using the mobile programming unit (MDU) during start-up. In case of questions concerning the firmware version or the procedure please contact Häfele. -
Page 12: Approval According To Part 15 Of The Fcc Rules
7. Approval according to Part 15 of the FCC rules NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. -
Page 13: Conformité Selon Section 15 De La Réglementation De La Fcc
8. Conformité selon Section 15 de la réglementation de la FCC REMARQUE : Cet appareil a été testé et entre dans la catégorie des appareils numériques de Classe B, selon la Section 15 de la réglementation de la FCC. Ces limites ont été conçues pour apporter une protection raisonnable aux installations domestiques contre les interférences néfastes. - Page 15 Lieferumfang „mm“ Index Description Index Description Interior Module Plate for Square Spindle Battery Cover Mounting Screw Interior Modul Screw Cover Forend Screw Battery Compartment Screw Forend Plate Mortise Lock Cabel Drill Sleeve Mortise Lock Drill D13 Antenna Cabel Drill D9 Exterior Module Drill Template Lever Handle...
- Page 16 Bohrbild...
- Page 17 „inch“ „mm“ 2 ³/ “ = inch (69.85) = mm inside 1¼“ (31.75) 1“ (25.4) 4³/ “ (120.65) 8“ 7¹/ “ (203.2) (184) outside 1.88“ 2.48“ (48) (63.1)
- Page 18 „inch“ „mm“ 2 ³/ = inch (69.85) = mm ⁹/ “ 1¹/ “ 1¹/ “ (7.14) (31.75) (28.58) 1“ (25.4) 4⁷/ “ 3¹/ “ ¹/ “ (123.5) (12.7) (88.9) ¹/ “ (3.2)
- Page 20 Ø 9 mm Ø 13 mm „mm“ Ø 9 Ø 13 Ø 13...
- Page 21 Ø 9 mm Ø 13 mm Ø 25 mm...
- Page 22 Länge Profilzylinder „inch“ „mm“ ¹/ “ - ⁵/ “ 12-15 mm...
- Page 23 max. 1 Nm...
- Page 26 Hex insert 3.0 with pin 0.8 ‒ 1.2 Nm Hex insert 3.0 2.0 ‒ 2.4 Nm...
- Page 27 Hex insert 3.0 2.0 ‒ 2.4 Nm...
- Page 28 Hex insert 3.0 with pin...
- Page 32 Häfele GmbH & Co KG Adolf-Häfele-Str. 1 D-72202 Nagold Germany Tel.: +49 (0)74 52 / 95 - 0 Fax: +49 (0)74 52 / 95 - 2 00 E-mail: info@haefele.de Subsidiaries of Häfele: https://www.hafele.com/com/en/info/locations/9749/...
