Front Suspension - Team C Hyde Manual

1

Front Suspension

T02056 2.3 E-ring
....................................4
T02056 3x34.5 Hinge pin front inner
....................................2
2
Front Suspension
T02083 M3x15 Screw
...............4
T02059 Ball stud - long
........................2
3
Assemble in the specified order
1
2
3
T02056
T02056
1
2
3
T02083
Assemble left and right sides the same way
L
R
T02056
T02125
T02037
T02056
T02056
T02059
1
2
3
4
5
T02056
TG2029
T02059
T02126
T02008
T02109
L
R
