Transmission
T02121
T02079 5x10x4
Contain oil ball
Bearing
.....................4
T02051 5x16.8 idler gear shaft
........................1
T02041 5x8x6.7 Top shaft spacer
.....................1
12
Motor mounts
T02036
Apply grease
Apply threadlock
Screw
Cement
T02041
<Right>
T02079
T02121
T02079
T02052
T02051
Screw
Cement
T02082 M3x12 Screw
............1
<Left>
T02079
T02003
T02079
T02082(3x25)
T02082(3x25)
Screw
Cement
T02082(3x12)
T02082 M3x25 Screw
.........4
8
