Team C Hyde Manual page 9

26
Shock Absorber
TG2040 / TG2041 2.3 E-ring
..............................8
T02068 9.9x2.5 Shock Piston
.....................4
T02069 2.8x1.9 O-ring
.....................8
T02069 3.1x1mm Plastic Washer
........................4
TG2015 / TG2016 8x1 O-ring
........................4
T02114 5.8 Ball End
.....................4
T02137 5.8x6 Ball stud
..............................4
27
Shock Absorber
1
Put the oil
for Front(Short)
for Rear(Long)
x2
F
R
15
x2
Assemble as many times as specified
Put a little oil
TG2040
T02068
TG2040
TG2040(Short)
短
T02137
T02114
1
2
3
Assemble in the specified order
1
2
3
Front
x2
TG2015
T02069
T02069(2.8x1.9)
T02069(3x1mm)
T02069(2.8x1.9)
TG2015
TG2015(Short)
短
TG2015 / TG2016
2
for Front(Short)
for Rear(Long)
x2
F
R
Assemble front and rear sides the same way
F
R
Rear
x2
Put a little oil
T02069
T02069(2.8x1.9)
TG2041
T02069(3x1mm)
T02069(2.8x1.9)
T02068
TG2041
TG2041(Long)
長
T02137
T02114
TG2016
TG2016
TG2016(Long)
長
