23
Rear Suspension
T02112 4.8mm Ball End(Long)
..............................4
TG2010 3x72 Turnbuckle
..............................2
24
Rear Suspension
25
Main Chassis
T02083 M3x8 Screw
............2
TG2031
x2
Assemble as many times as specified
1:1
True-to -scale diagram
approx.53mm
TG2010
T02112
T02083(3x8)
Rear Upper
x2
1:1
T02112
14
