Fig. 1; Fig. 1A - Altronix PD16WCB Quick Start Manual

Fig. 1

PD16W
common
1 2 3 4 5 6 7 8
outputs
protected
outputs
3.5A 250V
Altronix is not responsible for any typographical errors. Product specifications are subject to change without notice.
140 58th Street, Brooklyn, New York 11220 USA, 718-567-8181, fax: 718-567-9056
website: www.altronix.com, e-mail: info@altronix.com, Lifetime Warranty, Made in U.S.A.
IIPD16W - Rev. 072505
9 10 11 12 13 14 15 16
N
P
For continuous protection against risk of fire
replace fuses with same type and rating.

Fig. 1a

XFMR Input
PD16WCB
1 2 3 4 5 6 7 8
*If DC power supply is used, connect
S P N N
P
B12H
9 10 11 12 13 14 15 16
common
outputs
protected
outputs
negative to "N" and positive
to "P" terminals.
N
P
MEMBER
