Handling Instruction
opticalCON
|
NAOBO
NEUTRIK USA INC.
NEUTRIK Tokyo Ltd.
USA
Japan
Tel.: +1 732/901 9488 Tel.: +81 3/3663 4733
NAOBO components
cable tie
2 screws
opticalCON chassis
connector (not included)
NAOBO housing
counter nut
90° rear-shell (use for 90° mount)
PG-gland
Screw NAOBO housing
gland
90° mount
Don't forget the 90° degree rear-shell
