7. Wrap the ODV power/data flat cable one time around the ferrite core provided in the kit.
Figure 7: Wrapping the Power/Data Cable around the Ferrite Core
8. Plug the Power/Data cable into J1 of the ODV2D-V2 Interface PCBA.
Figure 8: Plugging the Power/Data Cable into the ODV2D-V2 Interface PCBA
J1 Connector
ODV2D-V2 I/F PCBA
ODV2D-V2
Power/Data Cable
8
