Print Speed Limits
The print speed limits of 2-10 IPS are based on steady paper motion and the ability of the ODV2D-V2 camera system to
gather and process the data effectively in real-time. No higher than 8 IPS is recommended.
Print Bullseye Pattern
Peel/Tear Door Assembly
IMPORTANT The door on the ODV2D-V2 Peel/Tear Door Assembly must be in the CLOSED position when doing
any Field Calibration adjustments using the "Bullseye" pattern.
Navigating Control Panel to Print "Bullseye"
Unlock Control Panel
1. Press PAUSE
Note: If C/P has been already un-locked, skip to Select "Bullseye" pattern now.
2. Press UP
"ATTENTION"
"ENTER SWITCH"
"UNLOCKED" OR "LOCKED"
If LOCKED, then press again to UNLOCK.
Select "Bullseye" Test Pattern
1. Press the ENTER
2. Press RIGHT ARROW
3. Press the ENTER
4. Press the DOWN
5. Press the ENTER
6. Press the DOWN
Figure 27: Close Peel/Tear Door Assembly
key to take printer OFF-LINE, panel will display
and DOWN keys on control panel simultaneously and control will display:
key control panel will display
key until ODV2D-V2 menu
key and the following will be displayed
key to select Diagnostic
key and the following will be displayed
key until "Print Bullseye" is selected
.
.
is selected.
.
.
.
.
