10.

Functional Testing

1. Power printer OFF / ON before performing the Functional Testing.
2. Make sure there is sufficient media installed to perform this test.
3. Close the Tear Bar Door.
2D Validation Demo Page
1. Press
2. Press the
key until "Tools" have been selected
3. Press the
4. Press the
5. Press the
6. Press the
7. Press the
8. Press the Press the
and grade it.
NOTE: See (figure 40) below for screen image results.
Figure 47: Proper Rectangle Alignment Around Barcodes & Barcode Grades Image
key to take printer OFF-LINE
key control panel will display, panel should display
key control panel will display
key control panel will display
key control panel will display
key until "Barcode Demo 2D" is selected
key, and Barcode Demo 2D test pattern will begin to print a 1 Page 2D barcode image
.
.
.
.
.
.
.
37
