CAUTION: To prevent electrostatic damage to electronic components, always wear a properly grounded static
wrist strap when you work around the printed circuit boards.
3. Put on a static wrist strap and ground it to an unpainted part of the printer frame. Touch the frame with the hand
wearing the wrist strap.
4. Raise the media cover and remove the plastic plug from the frame opening and set it aside.
5. On the electronics side of the printer, use long nose pliers to hold and insert the provided wire saddle into the
frame boss opening.
Figure 4: Removing the Plastic Plug
Wire Saddle
Figure 5: Installing the New Wire Saddle
Plastic Plug
Frame Boss
