Figure 13: Plugging the Power/Data Cable into the ODV2D-V2
ODV2D-V2 Bracket Tabs
Split Grommet
Figure 14: Routing the Power/Data Cable on the Bracket and into the Frame Opening
3. Route the Power/Data cable between the printer frame and both ODV2D-V2 bracket tabs shown in Figure 14.
Make sure the cable is not pinched between the bracket and the frame.
