PH18100
BAYOU CREEK CEILING FAN
1-800-643-0067, 8 a.m. - 6 p.m., EST, Monday - Thursday, 8 a.m. -
1
ITEM #0955853
MODEL
#CAF48BNK5L
Español p. 21
4009654
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Harbor Breeze CAF48BNK5L
Summary of Contents for Harbor Breeze CAF48BNK5L
- Page 1 ITEM #0955853 BAYOU CREEK CEILING FAN MODEL #CAF48BNK5L Harbor Breeze® is a registered trademark Español p. 21 of LF, LLC. All Rights Reserved. ATTACH YOUR RECEIPT HERE 4009654 Purchase Date Questions, problems, missing parts? Before returning to your retailer, call our customer service department at 1-800-643-0067, 8 a.m.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Safety Information ......................... 2 Package Contents ........................ 4 Hardware Contents ........................... Preparation ........................... Initial Installation ........................Downrod-Style Fan Mounting ....................Closemount-Style Fan Mounting ................... Wiring ...........................11 Final Installation ........................12 Installing Fan Without Light Kit .................... Operating Instructions ......................17 Care and Maintenance ...................... - Page 3 SAFETY INFORMATION WARNING To reduce the risk of fire, electrical shock or personal injury, mount fan to outlet box marked "ACCEPTABLE FOR FAN SUPPORT OF 35 LBS. (15.9 KG) OR LESS" and use mounting screws provided with the outlet box. Most outlet boxes commonly used for the support of lighting fixtures are not acceptable for fan support and may need to be replaced.
-
Page 4: Package Contents
PACKAGE CONTENTS PART DESCRIPTION QUANTITY PART DESCRIPTION QUANTITY Downrod Switch Housing Cap Screw (preassembled) Canopy Finial (preassembled) Mounting Bracket Glass Shade (preassembled) Rubber Washer Motor Housing (preassembled) Yoke Cover Balancing Kit Light Kit Fitter Motor Screw Blade (preassembled) + 1 extra Bulb Washer (preassembled) Finial Plate (preassembled) -
Page 5: Hardware Contents
HARDWARE CONTENTS (shown actual size) Blade Fiber Screw Blade Qty. 1 Wire Washer Connector Qty. 15 + 1 extra Qty. 15 Qty. 4 + 1 extra PREPARATION Before beginning assembly of product, make sure all parts are present. Place motor on carpet or on foam to avoid damage to finish. - Page 6 INITIAL INSTALLATION 2. Determine mounting method to use. A. Downrod mount (standard or angled ceiling) 19° max. B. Closemount (standard ceiling only) IMPORTANT: If using the angle mount, check to make sure the ceiling angle is not steeper than 19°. *Helpful Hint: Downrod-style mounting is best suited for ceilings 8 ft.
-
Page 7: Downrod-Style Fan Mounting
INITIAL INSTALLATION Secure mounting bracket (C) to outlet box (not STANDARD ANGLE included) using screws, spring washers and flat MOUNT MOUNT washers provided with the outlet box. NOTE: It is very important you use the proper hardware when installing the mounting bracket (C) as this will support the fan. - Page 8 DOWNROD-STYLE FAN MOUNTING 2. Insert downrod (A) through canopy (B) and yoke cover (E). Then, thread wires from motor housing (D) up through downrod (A). 3. Slip downrod (A) into yoke, align holes and re-install pin (V) and clip (W). Tighten set screws and then tighten nuts.
-
Page 9: Closemount-Style Fan Mounting
DOWNROD-STYLE FAN MOUNTING If you decided to cut back the lead wires in Step 4, strip 1/2 in. of insulation from end of each wire -- white, black, green and blue (if applicable). Twist stripped ends of each strand of wire within the insulation with pliers (not included). - Page 10 CLOSEMOUNT-STYLE FAN MOUNTING Remove every other preassembled screw and lock washer from top of motor housing (D). Screw Washer 3. Pull wires up through hole in the middle of the canopy (B) and attach canopy (B) to motor Screw housing (D) using three screws and lock washers previously removed.
-
Page 11: Wiring
WIRING WARNING: To reduce the risk of fire, electrical shock or personal injury, each wire connector provided with this fan is designed to accept only one 12-gauge house wire and one lead wire from the fan. If your house wire is larger than 12-gauge or there is more than one house wire to connect to the corresponding fixture lead wires, consult an electrician. -
Page 12: Final Installation
WIRING 1c. FAN AND LIGHT CONTROLLED BY TWO FAN AND LIGHT CONTROLLED BY TWO WALL SWITCHES FAN AND LIGHT CONTROLLED BY TWO WALL SWITCHES WALL SWITCHES: If you intend to control the fan and light with separate wall switches, connect BLACK wire from fan to BLACK wire from the 120V POWER FROM CEILING... - Page 13 FINAL INSTALLATION Partially insert three blade screws (BB) along with three fiber blade washers (CC) into holes in blade (G). Align pegs on blade arm (J) with blade screws (BB), securing blade arm (J) to blade (G) by tightening blade screws (BB) starting with the one in the middle.
- Page 14 FINAL INSTALLATION 5. Connect WHITE molex wire from switch housing to WHITE molex wire from light kit fitter (F). Connect BLUE (or BLACK) molex wire from switch housing to BLACK molex wire from light kit fitter (F). Make sure molex connections are secure. Switch Housing Then, align holes in switch housing cap (M) with...
- Page 15 FINAL INSTALLATION 8. Locate rubber washer (Q), hex nut (K), finial plate (I), and finial (O) that were previously removed (Step 6, page 14). Place rubber washer (Q) inside glass shade (P) over center hole. Align hole in center of glass shade (P) with threaded rod on light kit fitter (F), allowing pull chains to come through corresponding holes in glass shade (P).
-
Page 16: Installing Fan Without Light Kit
INSTALLING FAN WITHOUT LIGHT KIT If you wish to use the fan WITHOUT the light kit, remove the three preassembled switch housing cap WHITE BLACK screws (N) from switch housing cap (M) located at top of light kit fitter (F). Remove the preassembled hex nut (K) and lock washer (L) from threaded rod at the top of light kit fitter (F). -
Page 17: Operating Instructions
OPERATING INSTRUCTIONS The pull chain located on the switch housing has four positions to control fan speed. One pull is HIGH, two is MEDIUM, three is LOW and four turns the fan OFF. Switch Housing The pull chain located in the center is used to turn the light ON or OFF. -
Page 18: Care And Maintenance
OPERATING INSTRUCTIONS 3a. In warmer weather, setting the reverse switch in the DOWN position will result in downward airflow creating a wind chill effect. 3b. In cooler weather, setting the reverse switch in the UP position will result in upward airflow that can help move stagnant, hot air off the ceiling area. -
Page 19: Troubleshooting
TROUBLESHOOTING WARNING: Before beginning work, shut off the power supply to avoid electrical shock. PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION Fan does not 1. Reverse switch not engaged. 1. Push switch firmly either left or move. right. 2. Power is off or fuse is blown. 2. -
Page 20: Limited Lifetime Warranty
LIMITED LIFETIME WARRANTY The distributor warrants this fan to be free from defects in workmanship and materials present at time of shipment from the factory for Lifetime limited from the date of purchase. This warranty applies only to the original purchaser. The distributor agrees to correct any defect at no charge or, at our option, replace the ceiling fan with a comparable or superior model.
